AI Features
|
AI+
|
|
Imaging Device
|
1/1.8''
|
|
Max Resolution
|
8MP 3840(H)×2160(V)@30fps
|
|
Min. Illumination
|
Color 0.009lux @ F1.6(AGC ON) ; B/W 0 lux @ IR ON
|
|
Focal Length (Zoom Ratio)
|
Motorized lens 2.8-12mm
|
|
Max. Aperture Ratio
|
Max. F1.2
|
|
Angular Field Of View
|
113(W)-48(T)° Vertical
|
|
Min. Object Distance
|
1.75m, T
|
|
IR LED
|
1
|
|
Warmlight
|
2
|
|
Red & Blue Light
|
2 (1 Red & 1 Blue)
|
|
IR Distance
|
30M
|
|
Warmlight Viewable Length
|
Up to 25m
|
|
Type Of Complementary Light
|
Default warm light, switchable infrared light
|
|
Motion Detection
|
Off/On (8 Level)
|
|
Wide Dynamic Range
|
WDR
|
|
Backlight Compensation
|
Off / User BLC
|
|
Digital Noise Reduction
|
3D DNR
|
|
Image Setting
|
Full Color Mode/Day&Night Mode/Smart IIIumination
|
|
White Balance
|
Auto/Manual
|
|
Electronic Shutter Speed
|
1/5 ~ 1/20000s
|
|
SD Storage
|
Micro SD slot, up to 256GB
|
|
Alarm
|
1 input, 1 output
|
|
Custom Voice
|
Yes
|
|
Hardware Reset
|
Yes
|
|
AI Features
|
Face Recognition, Pedestrian & Vehicle , Perimeter Intrusion , Line Crossing , Object Detection, Crossing Counting, Heat Map, Crowd Density , Queue Length , License Plate, Rare Sound, Intrusion, Region Entrance, Region Exiting
|
|
Ethernet
|
RJ45(10/100BASE-T)
|
|
Video Compression
|
H.265/H.264/H.265+/H2.64+/MJPEG
|
|
Resolution
|
Mainstream 8MP(3840x2160),5MP(2592x1944,3072x1728), 4MP(2592x1520),3MP(2304x1296),1080P(1920x1080) Substream 1080P(1920x1080),720P(1280x720),VGA(640x480) Mobile Stream VGA(640x480), QVGA(320x240)
|
|
Video Quality Adjustment
|
8Kbps ~ 16Mbps
|
|
Bitrate Control Method
|
CBR/VBR
|
|
IP
|
IPv6
|
|
Protocol
|
TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP, SMTP,NTP,UPnP,SNMP,HTTPS,FTP
,
Onvif
|
|
Security
|
IP address filter;complicated password; Authenticated username and password
|
|
Compatible Web Browsers
|
IE10/11, Safari V12.1/above, Firefox V.52/above, Google chrome V.57/above, Edge V.79/above
|
|
Operating Temperature
|
-35~+60°C/less than ≤ 90% RH
|
|
Ingress Protection
|
IP67
|
|
Input Voltage / Current
|
DC 12V/POE
|
|
Material
|
Metal
|
Deterrence Lights and Siren
