Imaging Device
|
1/2.7” Progressive CMOS
|
|
Total Pixels
|
2608 (H) × 1960 (V)
|
|
Effective Pixels
|
2608 (H) × 1960 (V)
|
|
Scanning System
|
progressive scanning
|
|
Min. Illumination
|
Color 0.04lux @ F1.6(AGC ON) ; B/W 0 lux @ IR ON
|
|
Video Output
|
BNC
|
|
Resolution
|
Mainstream 4MP(2688x1520),3MP(2304x1296), 1080P(1920x1080) Substream 1080P(1920x1080),720P(1280x720),VGA(640x480) Mobile Stream VGA(640x480), QVG(320x240))
|
|
Max. Framerate
|
5MP@20fps 4AHD/4CVI/4TVI
|
|
Focal Length (Zoom Ratio)
|
Motorized lens 2.8-12mm
|
|
Max. Aperture Ratio
|
F1.8-3.3
|
|
Angular Field Of View
|
106.6°-34.6°/V
|
|
Min. Object Distance
|
1.2m (W/T)
|
|
Lens Type
|
Motorized lens
|
|
Safety
|
CE LVD
|
|
EMC
|
CE EMC, FCC
|
|
ROHS
|
RoHS2.0
|
|
IR Distance
|
35M
|
|
On Screen Display
|
English
|
|
Day & Night
|
Ext / Color / B/W
|
|
Backlight Compensation
|
Off / User BLC
|
|
Wide Dynamic Range
|
DWDR (Off/On)
|
|
Digital Noise Reduction
|
2D DNR
|
|
Gain Control
|
Auto
|
|
White Balance
|
ATW
|
|
Electronic Shutter Speed
|
Auto
|
|
Reverse
|
Mirror
|
|
Remote Control Interface
|
ACP (AHD Coax Protocol)
|
|
Video Transmission Distance
|
MAX 300M (RG-6)
|
|
Operating Temperature/Humidity
|
-30°C ~ 55°C / 90%
|
|
Ingress Protection
|
IP66
|
|
Input Voltage / Current
|
12V DC
|
|
Power Consumption
|
IR OFF ≤1W, IR ON ≤4W
|
|
Dimensions
|
Ø148.7x109mm
|
|
Weight
|
appr 930g
|
|
AI Features
|
AI+
|
True WDR
