- Image Sensor
- 1/2.7” Progressive Scan CMOS
- Max. Resolution
- 5120x1440
- Min. Illumination
- 0.001 Lux @ (F1.6, AGC ON), B/W
- Shutter Speed
- 1/5 s to 1/20000 s
- Slow Shutter
- Yes
- Day & Night
- IR cut filter
- Focal Length
- 2.8mm
- FOV
- 180°
- Aperture
- F1.0
- Supplement Light Range
- Up to 30m / Warm light
- Supplement Light Type
- IR and Warm Light
- Main Stream
- 25 fps @ 5120x1440; 4608x1296;4096x1152;3840x1080;3072x864 60 Hz
- Sub-Stream
- 25 fps @2048x576; 1536x432;1024x288 60 Hz
- Third Stream
- 25 fps @1920x540; / 60 Hz
- Video Compression
- H.265+/H.265/H.264+/H.264 Sub-stream
- Video Bit Rate
- 8 kbps to 16384kbps
- H.264 TYPE
- Baseline Profile/Main Profile/High Profile
- H.265 TYPE
- Main Profile
- Region Of Interest (ROI)
- N/A
- Audio Compression
- G711A, G711U
- Event
- MD (Sensitivity Level 1~8) Videlo loss Beep, Email, Push notification to Mobile APP
- Deep Learning Function
- Face Recognition, Human & Vehicle Detection, Perimeter Intrusion Detection, Line Crossing Detection, Stationary Object Detection, Crossing Counting, Heat Map, Crowd Density Detection, Queue Length Detection, License Plate Detection
- Protocols
- IPv4/IPv6, HTTP, HTTPS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP/IP, UDP, DHCP, PPPoE,
- API
- Onvif ( Profile S, Profile G, Profile T),Http API
- Simultaneous
- Live View Up to 15 channels
- User/Host
- 5 Users
- Security
- Password protection, complex password, HTTPS encryption, IP address filter, timeout control settings.
- Client
- VMS
- Web Browser
- IE11, Chrome 57+, Firefox 52+, Safari 11+
- Day/Night Switch
- Day, Night, Auto, Schedule
- Image Enhancement
- BLC, HLC, 3D DNR
- Wide Dynamic Range (WDR)
- DWDR
- Image Settings
- Saturation, brightness, contrast, sharpness, Hue and white balance adjustable by client software or web browser
- Privacy
- 4 Privacy Masks
- Ethernet Interface
- 1 RJ45 10M/100M self-adaptive Ethernet port
- On-Board Storage
- Built-in memory card slot, supports micro SD/SDHC/SDXC card, up to 256 GB
- Alarm
- Built-in red & blue flashing lights
- Audio
- Built-in microphone
- Reset
- Yes
- Built-In Speaker
- 1 built-in speaker
- Power
- DC12V&POE (<12W, IEEE802.3af)
- Operating Conditions
- -30~+60°C/ less then ≤ 90% RH
- Material
- Metal
- Dimensions
- Ø 136 mm × 127 mm (Ø 5.35” × 5”)
- Protection
- IP66
