- Imaging Device
- 1/2.8"
- Effective Pixels
- 8MP 3840(H)×2160(V)
- Scanning System
- Progressive CMOS
- Min. Illumination
- Color 0.007lux @ F1.0(AGC ON) ; B/W 0 lux @ IR ON
- Focal Length (Zoom Ratio)
- 2.0mm
- Max. Aperture Ratio
- F No. 2.4
- Angular Field Of View
- 180°; Vertical
- Min. Object Distance
- 0.6 m
- Lens Type
- M12
- IR LED
- 2
- Warmlight
- 2
- IR Viewable Length
- Up to 25m
- Warmlight Viewable Length
- Up to 15m
- Backlight Compensation
- Off/On (5 Zones)
- Wide Dynamic Range
- 120 dB
- Digital Noise Reduction
- 3D DNR
- Motion Detection
- Off/On (8 Levels)
- Image Settings
- Day&Night Mode/Full Color Mode/Schedule
- Privacy Masking
- Off/On (4 Zones, Rectangle)
- Gain Control
- Auto
- White Balance
- Auto/Manual
- Electronic Shutter Speed
- 1/5 ~ 1/20000s
- On-Board Storage
- Micro SD slot, up to 1TB
- Alarm
- Built-in red & blue deterrence lights
- Audio
- Built-in microphone, speaker
- Hardware Reset
- Yes
- AI Features
- PID,LCD,PD/VD,SOD,CC,Heat MAP,RSD
- Ethernet
- RJ45(10/100BASE-T)
- Video Compression Format
- H.265/H.264
- Resolution
- Main Stream 50/60Hz @ 20fps,8MP(3840x2160),5MP(2592x1944,3072x1728), 4MP(2592x1520),3MP(2304x1296),1080P(1920x1080), 960P(1280*960),720P(1280x720), Sub Steam 50/60Hz @ 20fps,720P(1280x720),VGA(640x480) Mobile Stream 50/60Hz @ 20fps,VGA(640x480)
- Video Quality Adjustment
- 256Kbps ~ 16Mbps
- Bitrate Control Method
- CBR/VBR
- Streaming Capability
- Triple-Stream(Main/Sub/Mobile)
- IP
- IPv4/IPv6
- Protocol
- TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP, SMTP,NTP,UPnP,SNMP,HTTPS,FTP
- Security
- IP address filter;complicated password; Authencated username and password
- Streaming Method
- Unicast/Multicast
- Application Programming Interface
- ONVIF( Profile S/G/T)
- Web Viewer
- IE10/11, Safari V12.1 above, Firefox V.52 above, Google chrome V.57 above, Edge V.79 above
- Operating Conditions
- -35~+60°C/less than ≤ 95% RH
- Ingress Protection
- IP67
- Input Voltage / Current
- D12V/POE(IEEE802.3af)
- Power Consumption
- Max. 13.1W
- Material
- Metal
- Dimensions
- 133.9mm x 108.25mm (5.27”x4.26”)
- Weight
- Approx. 705g (1.55 lb.)
