Imaging Device
|
1/1.8''
|
|
Effective Pixels
|
8MP 3840(H)×2160(V)
|
|
Scanning System
|
Progressive CMOS
|
|
Min. Illumination
|
0.0008 Lux @ (F1.7, AGC ON);0 Lux with IR
|
|
IR LED
|
8
|
|
Warmlight
|
4
|
|
IR Viewable Length
|
Up to 100m
|
|
Warmlight Viewable Length
|
Up to 30m
|
|
Type Of Complementary Light
|
Default warm light, switchable infrared light
|
|
Motion Detection
|
Off/On (8 Levels)
|
|
Wide Dynamic Range
|
120dB
|
|
Digital Noise Reduction
|
3D DNR
|
|
Image Setting
|
Full Color Mode/Day&Night Mode/Smart IIIumination
|
|
White Balance
|
Auto/Manual
|
|
Electronic Shutter Speed
|
1/5 ~ 1/20000s
|
|
On-Board Storage
|
Micro SD slot, up to 1TB
|
|
Alarm
|
2 inputs, 2 outputs
|
|
Audio
|
Built-in microphone & Speaker; 1 input (RCA), 1 output (RCA)
|
|
DUAL MODES
|
Customizable Voice
|
|
DUAL Light Sources
|
24/7 All-weather Color Images
|
|
Hardware Reset
|
Yes
|
|
Focal Length (Zoom Ratio)
|
8-32mm (fast zoom)
|
|
Max. Aperture Ratio
|
F1.7 to F 1.76
|
|
Min. Object Distance
|
1.5 m ~ INF, T
|
|
IRIS Type
|
Precise iris
|
|
Custom Voice
|
Yes
|
|
Smart Features
|
Rare Sound Detection (SD) , Face Detection (FD), Stationary Object Detection (SOD), Crowd Density Detection (CD), Human&Vehicle Detection (PD&VD), Line Crossing Detection (LCD), Queue Lenght Detection (QD), Heat Map (HM), Cross Counting (CC), License Plate Detection (LPD), Region Entrance and Exiting (RE), Intrusion
|
|
LPR Vehicle Speed
|
Up to 120km/h
|
|
Focal Length (Zoom Ratio)
|
8-32mm (fast zoom)
|
|
Max. Aperture Ratio
|
F1.7 to F 1.76
|
|
Angular Field Of View
|
40(W)-14(T)° V
|
|
Min. Object Distance
|
1.5 m ~ INF, T
|
|
IRIS Type
|
Precise iris
|
|
Ethernet
|
RJ45(10/100BASE-T)
|
|
Video Compression
|
H.265/H.264/H.265+/H.264+/MJPEG
|
|
Resolution
|
8MP(3840x2160), 5MP(3072x1728,2592x1944), 4MP(2592x1520), 3MP(2304x1296), 1080P(1920x1080), 720P(1280x720) Sub Stream @30fps
|
|
Video Quality Adjustment
|
256Kbps ~ 16Mbps
|
|
Bitrate Control Method
|
CBR/VBR
|
|
IP
|
IPv6
|
|
Protocol
|
TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP, SMTP,NTP,UPnP,SNMP,HTTPS,FTP
|
|
Security
|
IP address filter;complicated password; Authenticated username and password
|
|
Application Programming Interface
|
ONVIF( Profil S/G/T)
|
|
Compatible Web Browsers
|
IE10/11, Safari V12.1/above, Firefox V.52/above, Google chrome V.57/above, Edge V.79/above
|
|
Ingress Protection
|
IP67, IK10, NEMA 4X
|
|
Operating Conditions
|
-35°~+60°C/less than ≤ 90% RH
|
|
Input Voltage / Current
|
D12V/POE
|
|
Power Consumption
|
max 10.24W; POE (48V)
|
|
Material
|
Metal
|
|
Dimensions (LXHXP)
|
353.8mm×135.2mm
|
Deterrence Lights
