- Imaging Sensor
- 1/2.7” Progressive Scan CMOS
- Max. Resolution
- 3840x2160
- Min. Illumination
- 0.009 Lux @ (F1.6, AGC ON), B/W
- Shutter Speed
- 1/5 s to 1/20000 s
- Slow Shutter
- Yes
- Day & Night
- IR Cut Filter
- Zoom
- 4x optical
- Focal Length
- 2.8 mm to 12 mm
- FOV
- 113° to 31.4° (wide-tele) Vertical field of view
- Aperture
- Max. F1.6
- Focus
- Auto,manual
- Supplement Light Range
- up to 30 m
- Supplement Light Type
- IR
- Movement Range(PAN)
- 350°
- Movement Range(TILT)
- 0° to 90°
- Pan Speed
- configurable from 0.6° to 54°/s
- Tilt Speed
- configurable from 0.6° to 52°/s
- Presets
- 255 (Preset calls have a limit of 20,000 times)
- 3D Positioning
- Yes (without ZOOM in)
- Day/Night Switch
- Day, Night, Auto, Schedule
- Image Enhancement
- BLC, HLC, 3D DNR
- Wide Dynamic Range (WDR)
- DWDR
- DEFOG
- NA
- Image Stabilization
- NA
- Privacy
- 4 Privacy Masks
- Main Stream
- 25 fps (3840x2160, 3072x1728, 2592x1944, 2592x1520, 2304,1296, 1920x1080, 1280x960, 1280x720)
- Sub-Stream
- 25 fps (1280x720, 640×480, 320x240)
- Third Stream
- 25 fps (640x480,320x240)
- Video Compression
- H.265+/H.265/H.264+/H.264 Sub-stream
- Video Bit Rate
- 8 kbps to 16384kbps
- H.264 TYPE
- Baseline Profile/Main Profile/High Profile
- H.265 TYPE
- Main Profile
- Region Of Interest (ROI)
- NA
- Audio Compression
- G.711a/G.711u
- Protocols
- IPv4/IPv6, HTTP, HTTPS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, TCP/IP, UDP, DHCP, PPPoE,
- API
- Onvif ( Profile S, Profile G, Profile T),Http API
- Simultaneous
- Live View Up to 15 channels
- User/Host
- 5 User
- Security
- Password protection, complicated password, HTTPS encryption, IP address filter,control timeout settings
- Client
- VMS
- Image Settings
- Saturation, brightness, contrast, sharpness, Hue and white balance adjustable by client software or web browser
- Web Browser
- IE11, Chrome 57+, Firefox 52+, Safari 11+
- Basic Event
- Motion detection
- Deep Learning Function
- Face Recognition, Human & Vehicle Detection, Perimeter Intrusion Detection, Line Crossing Detection, Stationary Object Detection, Crossing Counting, Heat Map, Crowd Density Detection, Queue Length Detection, License Plate Detection
- Smart Tracking
- NA
- Alarm Linkage
- Upload to FTP, send email, trigger recording, audible warning, lights flashing
- Ethernet Interface
- 1 RJ45 10M/100M self-adaptive Ethernet port
- On-Board Storage
- Built-in memory card slot, support microSD/ SDHC/SDXC card, up to 256 GB
- Alarm
- Built-in red & blue flashing lights
- Audio
- 1 built-in MIC
- Reset
- Yes
- Built-In Speaker
- 1 built-in speaker
- Power
- DC 12V/POE, max. 13 W
- Operating Conditions
- -30 °C to 60 °C (-22 °F to 149 °F) Humidity 90% or less (non-condensing)
- Material
- Plastic
- Dimensions
- Ø 166.75 mm × 238 mm (Ø 6.56” × 9.37”)
- Weight
- Approx. 0.92 kg (2 lb.)
- Protection
- IP66
