Color
|
WHITE
,
BLACK
|
|
Imaging Device
|
1/2.7”
|
|
Effective Pixels
|
5MP 2880 (H) x 1620 (V)
|
|
Scanning System
|
Progressive CMOS
|
|
Min. Illumination
|
Color 0.002lux @ F1.0(AGC ON) ; B/W 0 lux @ IR ON
|
|
Focal Length (Zoom Ratio)
|
2.8 mm
|
|
Max. Aperture Ratio
|
F No. 1.0
|
|
Angular Field Of View
|
110°, Vertical
|
|
Min. Object Distance
|
2m
|
|
Lens Type
|
Fixed (M12)
|
|
IR LED
|
1
|
|
Warmlight
|
2
|
|
Red & Blue Light
|
2 (1 Red & 1 Blue)
|
|
IR Viewable Length
|
Up to 25m
|
|
Warmlight Viewable Length
|
Up to 20m
|
|
Type Of Complementary Light
|
Default warm light, switchable infrared light
|
|
Wide Dynamic Range
|
90dB
|
|
Digital Noise Reduction
|
3D DNR
|
|
Motion Detection
|
Off/On (8 Level)
|
|
Image Setting
|
Day&Night Mode/Full Color Mode/Schedule
|
|
White Balance
|
Auto/Manual
|
|
Electronic Shutter Speed
|
1/5 ~ 1/20000s
|
|
SD Card
|
Micro SD Card Slot Up To 256GB
|
|
Alarm
|
No
|
|
Audio
|
Built-in microphone & speaker
|
|
Custom Voice
|
Yes
|
|
Hardware Reset
|
Yes
|
|
AI Features
|
Rare Sound Detection (SD) , Perimeter Intrusion Detection (PID), Face Detection (FD), Stationary Object Detection (SOD), Crowd Density Detection (CD), Human&Vehicle Detection (PD&VD), Line Crossing Detection (LCD), Queue Lenght Detection (QD), Heat Map (HM), Cross Counting (CC), License Plate Detection (LPD)
|
|
Ethernet
|
RJ45(10/100BASE-T)
|
|
Video Compression Format
|
H.265/H.264
|
|
Resolution
|
Mainstream @30fps 5MP(2880x1620), 4MP(2560x1440) 3MP(2304x1296), 1080P(1920x1080), 720P(1280x720) Substream @30fps 720P(1280x720), VGA(640x480), QVGA(320x240) Mobile Stream @30fps VGA (640x480), QVGA (320x240)
|
|
Video Quality Adjustment
|
256Kbps ~ 8Mbps
|
|
Bitrate Control Method
|
CBR/VBR
|
|
IP
|
IPv6
|
|
Protocol
|
TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP, SMTP,NTP,UPnP,SNMP,HTTPS,FTP
|
|
Security
|
IP address filter;complicated password; Authenticated username and password
|
|
Application Programming Interface
|
ONVIF( Profil S/G/T)
|
|
Compatible Web Browsers
|
IE10/11, Safari V12.1/above, Firefox V.52/above, Google chrome V.57/above, Edge V.79/above
|
|
Operating Conditions
|
-35°+60°C/ Less than ≤ 95% RH
|
|
Ingress Protection (Waterproof)
|
IP67
|
|
Input Voltage / Current
|
D12V/POE (IEEE802.3af)
|
|
Power Consumption
|
max 5.8W; POE (48V)
|
|
Material
|
Metal
|
|
Dimensions
|
100*100*90mm
|
|
Weight
|
425g
|
5MP Resolution
