- Imaging Device
- 1/2.8"
- Effective Pixels
- 12MP 3536(H)×3536(V)
- Scanning System
- Progressive CMOS
- Min. Illumination
- Color 0.009lux @ F1.6(AGC ON) ; B/W 0 lux @ IR ON
- Focal Length (Zoom Ratio)
- 2.8 mm
- Max. Aperture Ratio
- F No. 1.6
- Angular Field Of View
- 105°, Vertical
- Min. Object Distance
- 1.8m
- Lens Type
- Fixed (M12)
- IR Viewable Length
- Up to 30m
- Camera Title
- Show/Hide
- Day & Night
- IR cut filter with auto switch (Day/Night/Auto/Image/Schedule)
- Backlight Compensation
- Off/On (5 Zones)
- Wide Dynamic Range
- WDR
- Digital Noise Reduction
- 3D DNR
- Motion Detection
- Off/On (8 Levels)
- Privacy Masking
- Off/On (4 Zones, Rectangle)
- Gain Control
- Auto
- White Balance
- Auto/Manual
- Electronic Shutter Speed
- 1/5 ~ 1/20000s
- On-Board Storage
- Micro SD slot, up to 1TB
- Alarm
- NA
- Audio
- Built-in microphone
- Hardware Reset
- Yes
- Smart Features
- Rare Sound Detection (SD) , Perimeter Intrusion Detection (PID), Face Detection (FD), Stationary Object Detection (SOD), Crowd Density Detection (CD), Human&Vehicle Detection (PD&VD), Line Crossing Detection (LCD), Queue Lenght Detection (QD), Heat Map (HM), Cross Counting (CC), License Plate Detection (LPD)
- Ethernet
- RJ45(10/100BASE-T)
- Video Compression Format
- H.265/H.264
- Resolution
- Mainstream@30fps 8MP(3840x2160), 5MP(2592x1944) (3072x1728), 4MP(2592x1520), 3MP(2304x1296), 1080P(1920x1080), 960P(1280x960), 720P(1280x720) Substeam@30fps 1080P(1920x1080), 720P(1280x720), VGA(640x480) Mobilestream@30fps VGA(640x480), QVGA (320x240)
- Video Quality Adjustment
- 256Kbps ~ 16Mbps
- Bitrate Control Method
- CBR/VBR
- Streaming Capability
- Triple-Stream(Main/Sub/Mobile)
- Protocol
- TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP, SMTP,NTP,UPnP,SNMP,HTTPS,FTP
- Security
- IP address filter;complicated password; Authenticated username and password
- Streaming Method
- Unicast/Multicast
- Application Programming Interface
- ONVIF( Profile S/G/T)
- Compatible Web Browsers
- IE10/11, Chrome V.57/above, Firefox V.52/above, Safari V.12.1/above, Edge V.79/above
- Operating Conditions
- -35°+60°C/less than ≤ 95% RH
- Ingress Protection
- IP67
- Input Voltage / Current
- D12V/POE(IEEE802.3af)
- Power Consumption (IR OFF)
- 3W-4W
- Color
- WHITE
- Power consumption (IR ON)
- 5W-6.5W
- Color/material
- White/Metal
- Dimension (WXHXD)
- Ø100x90mm
- Weight
- appr. 420g
