- Imaging Device
- 1/2.8” Progressive CMOS
- Total Pixels
- 2704 (H) × 2104 (V)
- Effective Pixels
- 2616 (H) × 1964 (V)
- Scanning System
- progressive scanning
- Min. Illumination
- Color 0.02lux @ F1.6(AGC ON) ; B/W 0 lux @ IR ON
- Video Output
- BNC
- Resolution
- 5MP 2592(H) × 1944(V)
- Max. Framerate
- 5MP@20fps 4AHD/4CVI/4TVI
- Focal Length (Zoom Ratio)
- 2.7-13.5mm
- Max. Aperture Ratio
- F1.8-3.3
- Angular Field Of View
- 110.6-32.6° / V
- Min. Object Distance
- 0.8m~INF(W),1m~INF(T)
- Lens Type
- Varifocal Lens
- Safety
- CE LVD
- EMC
- CE EMC, FCC
- ROHS
- RoHS2.0
- Viewable Length
- Up to 35m
- On Screen Display
- English
- Day & Night
- Ext / Color / B/W
- Backlight Compensation
- Off / User BLC
- Wide Dynamic Range
- WDR (Off/On) 120db
- Digital Noise Reduction
- 3D DNR
- Gain Control
- Auto
- White Balance
- ATW
- Electronic Shutter Speed
- Auto
- Reverse
- Mirror
- Remote Control Interface
- ACP (AHD Coax Protocol)
- Video Transmission Distance
- MAX 300M (RG-6)
- Operating Temperature/Humidity
- -30°C ~ 55°C / 90%
- Ingress Protection
- IP66
- Input Voltage / Current
- 12V DC
- Power Consumption
- IR OFF ≤2W, IR ON ≤6.5W
- Color/material
- metal
- Dimension (WXHXD)
- Ø135.56x127.04mm
- Weight
- appr. 850g
