- Imaging Device
- 1/2.7” Progressive CMOS
- Total Pixels
- 3872 (H) ×2180 (V)
- Effective Pixels
- 3840 (H) ×2160 (V)
- Scanning System
- progressive scanning
- Min. Illumination
- Color 0.05lux @ F1.2(AGC ON) ; 0 lux @ IR ON
- Video Output
- BNC
- Resolution
- 8MP 3840 (H) ×2160 (V)
- Max. Framerate
- 8MP@15fps CVBS
- Focal Length (Zoom Ratio)
- 2.8 mm
- Max. Aperture Ratio
- F2.0
- Angular Field Of View
- 102° / V
- Min. Object Distance
- 0.6 m
- Lens Type
- Fixed lens
- Safety
- CE LVD
- EMC
- CE EMC, FCC
- ROHS
- RoHS2.0
- IR Distance
- 20M
- On Screen Display
- English
- Day & Night
- Smart / Auto / Color / B/W
- Backlight Compensation
- GLOBAL / BLC
- Wide Dynamic Range
- D-WDR (Off/On)
- Digital Noise Reduction
- 2D DNR
- Gain Control
- HIGH
- White Balance
- ATW
- Electronic Shutter Speed
- Auto
- Reverse
- Mirror
- Remote Control Interface
- ACP (AHD Coax Protocol)
- Video Transmission Distance
- MAX 300M (RG-6)
- Operating Temperature/Humidity
- -30°C ~ 55°C / 90%
- Ingress Protection
- IP66
- Input Voltage / Current
- 12V DC
- Power Consumption
- 5W, IR OFF
- Color/material
- metal
- Dimensions
- Ø108.8x98.6mm
- Weight
- appr 430g
