- Power Supply Mode
- Mains on load
- Voltage Range
- AC 100-240V
- Power Consumption
- The device <15W, POE power supply <500W
- Network Ports
- 10/100/1000 BASE-T RJ45 Auto-MDI/MDI-X port 4 additional Gigabit TP/SFP combo ports
- Transmission Distance
- 0~100m 4 Ethernet Uplink Port
- Transmission Media
- Cat5e/6 standard UTP cable 4 Ethernet Uplink Port
- POE Agreement
- IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet Plus
- POE Power Supply Mode
- End-Span Method
- POE Power Supply Wattage
- Each port≤30W, Whole device<500W
- Network Standard
- IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3ab Gigabit 1000BASE-T IEEE 802.3z Gigabit SX/LX IEEE 802.3x flow control and back pressure
- Swap Mode
- Store-and-forward
- Switch Capacity
- 56Gbps
- Mac Address List
- 8K
- Power Indicator Light
- One power light (green)
- Optical Fiber Port Indicator
- One fiber link indication light ( green) Green light keeps on when the fiber port is well connected; Blinking when transceiver data
- Uplink Port
- On, port is link on; Off, port is link down;
- POE Indicator
- 1~24 PoE indicator light
- POE Network Port LED
- 1~24 port ( green light on RJ45 jack) Keeps on when normally connected, Blinking when transceiver data
- Surge Immunity
- IEC61000-4-5
- Electrostatic Protection
- level 3 1a Air discharge
- Working Temperature
- -10°C~ 55°C
- Storage Temperature
- -40°C~ 85°C
- Humidity (Non-Congeal)
- 5~95%
- Dimensions (L*W*H)
- 440mm×290mm×45mm
- Color
- BLACK
- Weight
- 4.5kg
- Mean Time Between Failures (MTBF)
- >50000h
