Up to 30 Watts Per Port
PRODUCT SPECIFICATIONS
| Power Supply Mode | Mains on load |
| Voltage Range | AC 100-240V |
| Power Consumption | The device <15W, POE power supply <400W |
| Network Ports | 10/100/1000Mbps Ethernet port, adaptive control UPLINK Ethernet port |
| Transmission Distance | 0~100m 2 Ethernet Uplink Port |
| Transmission Media | Cat5e/6 standard UTP cable 2 Ethernet Uplink Port |
| POE Agreement | IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet Plus |
| POE Power Supply Mode | End-Span Method |
| POE Power Supply Wattage | Each port≤30W,Whole device<400W |
| Network Standard | IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3ab Gigabit 1000BASE-T IEEE 802.3z Gigabit SX/LX IEEE 802.3x flow control and back pressure |
| Swap Mode | Store-and-forward |
| Switch Capacity | 56Gbps |
| Mac Address List | 8K |
| Power Indicator Light | One power light (green) |
| Optical Fiber Port Indicator | One fiber link indication light ( green) Green light keeps on when the fiber port is well connected; Blinking when transceiver data |
| Uplink Port | On, port is link on; Off, port is link down; |
| POE Indicator | 1~24 PoE indicator light |
| POE Network Port LED | 1~24 port ( green light on RJ45 jack) Keeps on when normally connected, Blinking when transceiver data |
| Surge Immunity | IEC61000-4-5 |
| Electrostatic Protection | level 3 1a Air discharge |
| Working Temperature | -10°C~ 55°C |
| Storage Temperature | -40°C~ 85°C |
| Humidity (Non-Congeal) | 5~95% |
| Dimensions (L*W*H) | 440mm×290mm×45mm |
| Color | BLACK |
| Weight | 4.5kg |
| Mean Time Between Failures (MTBF) | >50000h |
