- Interfaces
- 16x10/100M POE+2x100/1000M Gigabit Ethernet
- Network Management
- Lite Manager (CMS connection ,POE power consumer statistics, parameter configuration, log checking, firmware update, network topology)
- IEEE Standard
- IEEE 802.3\802.3u\802.3ab\802.3x\ 802.3z\802.3af\802.3at
- Uplink Rate (Individual Port)
- 1000M
- Downlink Rate (Individual Port)
- 1000M
- Exchange Capacity
- 7.2Gbps
- Packet Forwarding Rate
- 5.36Mpps
- Internal Cache
- 2.75Mbits
- POE Standard
- IEEE 802.3at/af
- POE Port
- 1~16
- Extension Mode (EPOE)
- 250 Meters
- Max. Power (Individual Port)
- 30W
- Max. Power (All Ports)
- 230W
- Case
- Metal
- Weight
- 2861g
- Dimension (WXHXD)
- 440*221*44mm
- Operating Temperature/Humidity
- -10°C~+50°C; Humidity
- Storage Temperature/Humidity
- -40°C~+85°C; Humidity
- Power Supply
- 100~240VAC 50/60Hz Max4A 52V/4.8A 250W
- Lightning Protection
- 4KV
