- Image Sensor
- 1/1.8”
- Max. Resolution
- 8MP 3840(H)×2160(V)@30fps
- Min. Illumination
- Color 0.001lux @ F1.2(AGC ON) ; B/W 0 lux @ IR ON
- Scanning System
- Progressive CMOS
- Focal Length (Zoom Ratio)
- 2.8 - 12 mm
- Max. Aperture Ratio
- Max. F1.2
- Angular Field Of View
- 113(W)-48(T)° Vertical
- Min. Object Distance
- 1.75m, T
- DORI
- D
- Movement Range(PAN)
- 350°
- Movement Range(TILT)
- 0° to 80°
- Pan Speed
- configurable from 0.6° to 54°/s
- Tilt Speed
- configurable from 0.6° to 52°/s
- Presets
- 255 (Preset calls have a limit of 20,000 times)
- EMC
- 2015+A1
- Safety
- EN IEC 62368-1
- Environment
- (EU) 2015/863
- Ethernet
- RJ45(10/100BASE-T)
- Video Compression
- H.265/H.264/H.265+/H.264+/MJPEG
- Resolution
- Mainstream@30fps 8MP(3840x2160),5MP(2592x1944,3072x1728), 4MP(2592x1520), 3MP(2304x1296),1080P(1920x1080), 960P(1280*960),720P(1280x720) Substeam@30fps 720P(1280x720),VGA(640x480),QVGA(320x240) Mobilestream@30fps VGA(640x480), QVGA(320x240)
- Video Quality Adjustment
- 256Kbps ~ 16Mbps
- Bitrate Control Method
- CBR/VBR
- IP
- IPv6
- Protocols
- TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP, SMTP,NTP,UPnP,SNMP,HTTPS,FTP
- Security
- IP address filter;complicated password; Authenticated username and password
- Protocol
- ONVIF( Profile S/G/T/M)
- Image Setting
- Full Color Mode/Day&Night Mode/Smart IIIumination
- Compatible Web Browsers
- IE10/11, Chrome V.57/above, Firefox V.52/above Safari V.12.1/above, Edge V.79/above
- Operating Temperature
- -35~+60°C/less than ≤ 90% RH
- Ingress Protection
- IP67
- Protection Rating
- IK10
- Input Voltage / Current
- DC12V/PoE(IEEE 802.3at)
- Power Consumption
- max 10.5W; POE(48V)
- Color/material
- White/Metal
- AI Features
- AI+
