Deterrence Lights and Siren
PRODUCT SPECIFICATIONS
| Image Sensor | 1/1.8” |
| Max. Resolution | 4MP 2688(H)×1520(V)@30fps |
| Min. Illumination | Color 0.0007 Lux @(F1.0, AGC ON) ; B/W 0 lux @ IR ON |
| Scanning System | Progressive CMOS |
| Focal Length | 2.8 mm to 12 mm |
| Max. Aperture Ratio | F 1.2 |
| Angular Field Of View | 113(W)-48(T)° Vertical |
| Min. Object Distance | 1.75m, T |
| DORI | D |
| Movement Range(PAN) | 350° |
| Movement Range(TILT) | 0° to 80° |
| Tilt Speed | configurable from 0.6° to 52°/s |
| Pan Speed | configurable from 0.6° to 54°/s |
| Presets | 255 (Preset calls have a limit of 20,000 times) |
| EMC | 2015+A1 |
| Safety | EN IEC 62368-1 |
| Environment | (EU) 2015/863 |
| Ethernet | RJ45(10/100BASE-T) |
| Video Compression | H.265/H.264/H.265+/H2.64+/MJPEG |
| Resolution | Mainstream@30fps 4MP(2688x1520),3MP(2304x1296),1080P (1920x1080) Substeam@30fps 1080P(1920x1080),720P(1280x720),VGA(640x 480) Mobilestream@30fps VGA(640x480), QVGA(320x240) |
| Video Quality Adjustment | 256Kbps ~ 8Mbps |
| Bitrate Control Method | CBR/VBR |
| IP | IPv6 |
| Protocols | TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP, SMTP,NTP,UPnP,SNMP,HTTPS,FTP |
| Security | IP address filter;complicated password; Authenticated username and password |
| Application Programming Interface | ONVIF( Profil S/G/T), HTTP API |
| Image Settings | Full Color Mode/Day&Night Mode/Smart IIIumination |
| Compatible Web Browsers | IE10/11 Safari V12.1 above Firefox V.52 above Google chrome V.57 above Edge V.79 above |
| Operating Conditions | -30~+60°C/ less then ≤ 90% RH |
| Protection Rating | IP67, IK10 |
| Input Voltage / Current | DC12V/PoE(IEEE 802.3at) |
| Power Consumption | max 10.5W; POE(48V) |
| Color/material | White/Metal |
