- Image Sensor
- 1/1.8”
- Max. Resolution
- 4MP 2688(H)×1520(V)@30fps
- Min. Illumination
- Color 0.0007 Lux @(F1.0, AGC ON) ; B/W 0 lux @ IR ON
- Scanning System
- Progressive CMOS
- Focal Length
- 2.8 mm to 12 mm
- Max. Aperture Ratio
- F 1.2
- Angular Field Of View
- 113(W)-48(T)° Vertical
- Min. Object Distance
- 1.75m, T
- DORI
- D
- Movement Range(PAN)
- 350°
- Movement Range(TILT)
- 0° to 80°
- Tilt Speed
- configurable from 0.6° to 52°/s
- Pan Speed
- configurable from 0.6° to 54°/s
- Presets
- 255 (Preset calls have a limit of 20,000 times)
- EMC
- 2015+A1
- Safety
- EN IEC 62368-1
- Environment
- (EU) 2015/863
- Ethernet
- RJ45(10/100BASE-T)
- Video Compression
- H.265/H.264/H.265+/H2.64+/MJPEG
- Resolution
- Mainstream@30fps 4MP(2688x1520),3MP(2304x1296),1080P (1920x1080) Substeam@30fps 1080P(1920x1080),720P(1280x720),VGA(640x 480) Mobilestream@30fps VGA(640x480), QVGA(320x240)
- Video Quality Adjustment
- 256Kbps ~ 8Mbps
- Bitrate Control Method
- CBR/VBR
- IP
- IPv6
- Protocols
- TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP, SMTP,NTP,UPnP,SNMP,HTTPS,FTP
- Security
- IP address filter;complicated password; Authenticated username and password
- Application Programming Interface
- ONVIF( Profil S/G/T), HTTP API
- Image Settings
- Full Color Mode/Day&Night Mode/Smart IIIumination
- Compatible Web Browsers
- IE10/11 Safari V12.1 above Firefox V.52 above Google chrome V.57 above Edge V.79 above
- Operating Conditions
- -30~+60°C/ less then ≤ 90% RH
- Protection Rating
- IP67, IK10
- Input Voltage / Current
- DC12V/PoE(IEEE 802.3at)
- Power Consumption
- max 10.5W; POE(48V)
- Color/material
- White/Metal
