- Image Sensor
- 1/1.8”
- Max. Resolution
- 8MP 3840x2160 (EA)
- Scanning System
- CMOS progressif
- Min. Illumination
- 0,006 Lux @ (F1.2, AGC ON), B/W
- Shutter Speed
- 1/5 s to 1/20000 s
- Day & Night
- IR Cut Filter
- Angle Adjustment
- -60° to 60°, Tilt
- Focal Length
- 2,8 à 12 mm Varifocal motorized lens
- Max. Aperture Ratio
- F1.30
- Angular Field Of View
- 48° à 112° Vertical field of view
- Lens Mount
- Ф16.7
- Supplement Light Type
- IR and Warm Light
- Supplement Light Range
- Up to 30 m (IR) / 15 m (Warm light)
- IR Wavelength
- 850mm
- Smart Supplement Light
- Yes
- Main Stream
- 25 fps 8MP(3840x2160),5MP(2592x1944,3072x1728), 4MP(2592x1520), 3MP(2304x1296),1080P(1920x1080), 960P(1280*960),720P(1280x720)
- Sub-Stream
- 25 fps 720P(1280x720), VGA(640x480),QVGA(320x240)
- Video Compression
- H.265+/H.265/H.264+/H.264 Substream
- Video Bit Rate
- 8 kbps to 16 Mbps
- H.264 TYPE
- Baseline Profile/Main Profile/High Profile
- H.265 TYPE
- Main Profile
- Region Of Interest (ROI)
- Yes
- Basic Event
- Motion detection
- Smart Features
- Rare Sound Detection (SD) , Perimeter Intrusion Detection (PID), Face Detection (FD), Stationary Object Detection (SOD), Crowd Density Detection (CD), Human&Vehicle Detection (PD&VD), Line Crossing Detection (LCD), Queue Lenght Detection (QD), Heat Map (HM), Cross Counting (CC), License Plate Detection (LPD)
- Audio Compression
- G.711
- Audio Bit Rate
- Auto
- Audio Sampling Rate
- 8 kHz
- Environment Noise Filtering
- Yes
- Ethernet
- 1 RJ45 10M / 100M / 1000M Ethernet port
- Protocols
- TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, UPnP, SNMP, HTTPS, FTP, PPPoE
- Application Programming Interface
- ONVIF( Profil S/G/T)
- Simultaneous
- Up to 92 flux
- User/Host
- Administrator and User
- Compatible Web Browsers
- IE 10/11, Chrome V.57/above, Firefox V.52/above, Safari V.12.1/above, Edge V.79/above.
- Image Settings
- Rotate mode, saturation, brightness, contrast, sharpness, and white balance are adjustable by client software or web browser
- Day/Night Switch
- Day/Night/Image/Schedule
- Wide Dynamic Range
- 120 dB
- Image Enhancement
- BLC, 3D DNR, HLC
- On-Board Storage
- Micro SD card slot SD/SDHC/SDXC, up to 256 Go
- Alarm
- 2 inputs, 2 outputs
- Ingress Protection
- IP67
- Power Consumption
- Max. 43W
- Color/material
- White/Alloy
- Package Dimension
- 500 mm × 395 mm × 385 mm
- Operating Conditions
- -30~+55°C/less thsan ≤ 95% HR
- Input Voltage / Current
- ACV24/DCV12/Hi-PoE
- Dimensions
- Ø300 mm × 195 mm
- Weight
- Approx. 4.6kg
- Protection Rating
- IK10
- Audio
- 1 input (RCA), 1 output (RCA)
- Hardware Reset
- Yes
