Image Sensor
|
1/1.8”
|
|
Max. Resolution
|
4MP 2560(H)x1440(V)
|
|
Scanning System
|
Progressive CMOS
|
|
Min. Illumination
|
0.001 Lux @ (F1.3, AGC ON), B/W
|
|
Shutter Speed
|
1/5 s to 1/20000 s
|
|
Slow Shutter
|
Yes
|
|
Day & Night
|
IR cut filter with auto switch (Color/Day/Night/Auto/Image/Schedule)
|
|
Zoom
|
4x optical
|
|
Focal Length (Zoom Ratio)
|
2.8 - 12 mm
|
|
Max. Aperture Ratio
|
Max. F1.3
|
|
Angular Field Of View
|
114.6° to 48.3° (wide-tele) Vertical
|
|
Focus
|
Auto/Manual
|
|
Supplement Light Range
|
up to 20 m
|
|
Supplement Light Type
|
IR & warm light
|
|
Movement Range(PAN)
|
350°
|
|
Movement Range(TILT)
|
0° to 80°
|
|
Pan Speed
|
configurable from 0.6° to 54°/s
|
|
Tilt Speed
|
configurable from 0.6° to 52°/s
|
|
Presets
|
255 (Preset calls have a limit of 20,000 times)
|
|
Main Stream
|
50fps (2560x1440/2304x1296/1920x1080/1280x720) 60Hz
|
|
Sub-Stream
|
50fps (1280x720/640x480/320x240) 60Hz
|
|
Third Stream
|
50fps (340x480/320x240) 60Hz
|
|
Video Compression
|
H.265+/H.265/H.264+/H.264 Substream
|
|
Video Bit Rate
|
8 kbps to 8192 kbps
|
|
H.264 TYPE
|
Baseline Profile/Main Profile/High Profile
|
|
H.265 TYPE
|
Main Profile
|
|
Region Of Interest (ROI)
|
N/A
|
|
Audio Compression
|
G.711a/G.711u
|
|
Protocols
|
IPv4/IPv6, HTTP, HTTPS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, TCP/IP, UDP, DHCP, PPPoE,
|
|
Application Programming Interface
|
ONVIF( Profil S/G/T), HTTP API
|
|
Simultaneous
|
Live View Up to 15 channels
|
|
User/Host
|
5 Users
|
|
Security
|
Password protection, complex password, HTTPS encryption, IP address filter, timeout control settings.
|
|
Client
|
VMS
|
|
Compatible Web Browsers
|
IE10/11, Chrome V.57/above, Firefox V.52/above Safari V.12.1/above, Edge V.79/above
|
|
Image Enhancement
|
BLC, HLC, 3D DNR
|
|
Wide Dynamic Range
|
120 dB
|
|
Image Settings
|
Saturation, brightness, contrast, sharpness, Hue and white balance adjustable by client software or web browser
|
|
Privacy Mask
|
Off/On (4 zones)
|
|
Smart Features
|
Perimeter Intrusion Detection (PID), Line Crossing Detection (LCD), Stationary Object Detection (SOD), Human&Vehicle Detection (PD&VD), Face Detection (FD), Cross Counting (CC), Crowd Density Detection (CD), Queue Lenght Detection (QD), Heat Map (HM)
|
|
Ethernet
|
1 RJ45 10M/100M self-adaptive Ethernet port
|
|
Ingress Protection
|
IP66
|
|
Color/material
|
White/Metal
|
|
Operating Conditions
|
-30~+60°C/ less then ≤ 90% RH
|
|
Input Voltage / Current
|
DC 12V/POE - MAX 13W
|
|
Dimensions
|
Ø 166.75 mm × 238 mm
|
|
Weight
|
appro. 920g
|
|
Protection Rating
|
IK10
|
|
Basic Event
|
Motion detection
|
|
Smart Tracking
|
N/A
|
|
On-Board Storage
|
Micro SD card slot SD/SDHC/SDXC, up to 256 Go
|
|
Alarm
|
N/A
|
|
Audio
|
Built-in microphone & speaker
|
|
Hardware Reset
|
Yes
|
True WDR
