- Image Sensor
- 1/1.8”
- Max. Resolution
- 4MP 2560(H)x1440(V)
- Scanning System
- Progressive CMOS
- Min. Illumination
- 0.001 Lux @ (F1.3, AGC ON), B/W
- Shutter Speed
- 1/5 s to 1/20000 s
- Slow Shutter
- Yes
- Day & Night
- IR cut filter with auto switch (Color/Day/Night/Auto/Image/Schedule)
- Zoom
- 4x optical
- Focal Length (Zoom Ratio)
- 2.8 - 12 mm
- Max. Aperture Ratio
- Max. F1.3
- Angular Field Of View
- 114.6° to 48.3° (wide-tele) Vertical
- Focus
- Auto/Manual
- Supplement Light Range
- up to 20 m
- Supplement Light Type
- IR & warm light
- Movement Range(PAN)
- 350°
- Movement Range(TILT)
- 0° to 80°
- Pan Speed
- configurable from 0.6° to 54°/s
- Tilt Speed
- configurable from 0.6° to 52°/s
- Presets
- 255 (Preset calls have a limit of 20,000 times)
- Main Stream
- 50fps (2560x1440/2304x1296/1920x1080/1280x720) 60Hz
- Sub-Stream
- 50fps (1280x720/640x480/320x240) 60Hz
- Third Stream
- 50fps (340x480/320x240) 60Hz
- Video Compression
- H.265+/H.265/H.264+/H.264 Substream
- Video Bit Rate
- 8 kbps to 8192 kbps
- H.264 TYPE
- Baseline Profile/Main Profile/High Profile
- H.265 TYPE
- Main Profile
- Region Of Interest (ROI)
- N/A
- Audio Compression
- G.711a/G.711u
- Protocols
- IPv4/IPv6, HTTP, HTTPS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, TCP/IP, UDP, DHCP, PPPoE,
- Application Programming Interface
- ONVIF( Profil S/G/T), HTTP API
- Simultaneous
- Live View Up to 15 channels
- User/Host
- 5 Users
- Security
- Password protection, complex password, HTTPS encryption, IP address filter, timeout control settings.
- Client
- VMS
- Compatible Web Browsers
- IE10/11, Chrome V.57/above, Firefox V.52/above Safari V.12.1/above, Edge V.79/above
- Image Enhancement
- BLC, HLC, 3D DNR
- Wide Dynamic Range
- 120 dB
- Image Settings
- Saturation, brightness, contrast, sharpness, Hue and white balance adjustable by client software or web browser
- Privacy Mask
- Off/On (4 zones)
- Smart Features
- Perimeter Intrusion Detection (PID), Line Crossing Detection (LCD), Stationary Object Detection (SOD), Human&Vehicle Detection (PD&VD), Face Detection (FD), Cross Counting (CC), Crowd Density Detection (CD), Queue Lenght Detection (QD), Heat Map (HM)
- Ethernet
- 1 RJ45 10M/100M self-adaptive Ethernet port
- Ingress Protection
- IP66
- Color/material
- White/Metal
- Operating Conditions
- -30~+60°C/ less then ≤ 90% RH
- Input Voltage / Current
- DC 12V/POE - MAX 13W
- Dimensions
- Ø 166.75 mm × 238 mm
- Weight
- appro. 920g
- Protection Rating
- IK10
- Basic Event
- Motion detection
- Smart Tracking
- N/A
- On-Board Storage
- Micro SD card slot SD/SDHC/SDXC, up to 256 Go
- Alarm
- N/A
- Audio
- Built-in microphone & speaker
- Hardware Reset
- Yes
