- Image Sensor
- 1/2.7”
- Max. Resolution
- 5MP 2592(H)×1944(V)
- Scanning System
- Progressive CMOS
- Min. Illumination
- 0,003 Lux @ (F1.6, AGC ON), B/W
- Shutter Speed
- 1/5 s to 1/20000 s
- Slow Shutter
- Yes
- Day & Night
- IR cut filter with auto switch (Day/Night/Auto/Image/Schedule)
- Zoom
- 33x optical
- Focal Length (Zoom Ratio)
- 4.3 - 142mm
- Max. Aperture Ratio
- Max. F1.6
- Angular Field Of View
- 55° à 2,3° (wide-tele) Vvertical
- Focus
- Auto/Manual
- Supplement Light Range
- Distance de l’IR jusqu’à 150 m
- Supplement Light Type
- IR
- Movement Range(PAN)
- 360°
- Movement Range(TILT)
- -10° to 90° (auto flip)
- Pan Speed
- 0.6° to 200°/s; preset speed
- Tilt Speed
- 0,6° to 90°/s preset speed
- Presets
- 255
- Patrol Scan
- 1 Scan
- Pattern Scan
- 4 pattern
- 3D Positioning
- Yes
- Protocols
- IPv4/IPv6, HTTP, HTTPS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP/IP, UDP, DHCP, PPPoE,
- Application Programming Interface
- ONVIF( Profil S/G/T), HTTP API
- Simultaneous
- Live View Up to 15 channels
- User/Host
- 5 Users
- Security
- Password protection, complicated password, HTTPS encryption, IP address filter,control timeout settings
- Client
- VMS
- Compatible Web Browsers
- IE10/11, Safari V12.1 above, Firefox V.52 above, Google chrome V.57 above, Edge V.79 above
- Main Stream
- 25fps(2592x1944/2592x1520/2048x1536/2304x1296/ 1920x1080/ 1280x960/1280x720) 60 Hz
- Sub-Stream
- 25 fps (1280x720/640x480/320x240) 60 Hz
- Third Stream
- 25 fps (640x480/320x240) 60 Hz
- Video Compression
- H.265+/H.265/H.264+/H.264 Sub-Stream
- Video Bit Rate
- 8 kbps to 8192 kbps
- H.264 TYPE
- Baseline Profile/Main Profile/High Profile
- H.265 TYPE
- Main Profile
- Region Of Interest (ROI)
- NA
- Audio Compression
- G.711a/G.711u
- Image Enhancement
- BLC, HLC, 3D DNR
- Wide Dynamic Range
- 120 dB
- Image Settings
- Saturation, brightness, contrast, sharpness, Hue and white balance adjustable by client software or web browser
- Privacy Mask
- Off/On (4 zones)
- Ethernet
- 1 port Ethernet RJ45 10M/100M auto-adaptatif
- On-Board Storage
- Micro SD card slot SD/SDHC/SDXC, up to 256 Go
- Alarm
- 1 input, 1 output
- Audio
- 1 Input, 1 Output
- Hardware Reset
- Yes
- Basic Event
- Motion detection, alarm input and output
- Smart Features
- FD, PD&VD, PID, CC, SOD, HM, CD, QD, LPD, LDC
- Smart Tracking
- auto-tracking
- Alarm Linkage
- Upload to FTP, send email, trigger alarm output, trigger recording
- Operating Conditions
- -30~+60°C/ less then ≤ 90% RH
- Ingress Protection
- IP66
- Input Voltage / Current
- DC 12V/POE+, max. 25.6 W
- Dimensions
- Ø 206.4 mm × 351.8 mm
- Weight
- appro. 3700g
