Imaging Sensor
|
1/2.8” Progressive Scan CMOS
|
|
Max. Resolution
|
8MP 3840x2160 (EA)
|
|
Min. Illumination
|
0.002 Lux @ (F1.6, AGC ON), B/W
|
|
Shutter Speed
|
1/5 s to 1/20000 s
|
|
Slow Shutter
|
Yes
|
|
Day & Night
|
IR cut filter
|
|
Zoom
|
25x optical
|
|
Focal Length
|
5.0 mm to 125 mm
|
|
FOV
|
56.9° to 2.9° (wide-tele) Vertical field of view
|
|
Aperture
|
Max. F1.5
|
|
Focus
|
Auto,manual
|
|
Supplement Light Range
|
up to 100 m
|
|
Supplement Light Type
|
IR and Warm Light
|
|
Movement Range(PAN)
|
360°
|
|
Movement Range(TILT)
|
-10° to 90° (auto flip)
|
|
Pan Speed
|
configurable from 0.6° to 80°/s; preset speed
|
|
Tilt Speed
|
configurable from 0.6° to 80°/s; preset speed
|
|
Presets
|
255
|
|
Patrol Scan
|
1 Scan
|
|
Pattern Scan
|
4 pattern
|
|
Power-Off Memory
|
Yes
|
|
3D Positioning
|
Yes
|
|
Day/Night Switch
|
Day, Night, Auto, Schedule
|
|
Image Enhancement
|
BLC, HLC, 3D DNR
|
|
Wide Dynamic Range (WDR)
|
120 dB
|
|
Defog & Image Stabilization
|
Digital
|
|
Image Settings
|
Saturation, brightness, contrast, sharpness, Hue and white balance adjustable by client software or web browser
|
|
Privacy
|
4 Privacy Masks
|
|
Main Stream
|
25 fps (1920 × 1080, 1280 × 960, 1280 × 720); 60 Hz
|
|
Sub-Stream
|
25 fps (640 × 480, 320x240); 60 Hz
|
|
Third Stream
|
25 fps (320x240); 60 Hz
|
|
Video Compression
|
H.265+/H.265/H.264+/H.264 Sub-stream
|
|
Video Bit Rate
|
8 kbps to 8192 kbps
|
|
H.264 TYPE
|
Baseline Profile/Main Profile/High Profile
|
|
H.265 TYPE
|
Main Profile
|
|
Region Of Interest (ROI)
|
NA
|
|
Audio Compression
|
G.711a/G.711u
|
|
Protocols
|
IPv4/IPv6, HTTP, HTTPS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, TCP/IP, UDP, DHCP, PPPoE,
|
|
API
|
Onvif ( Profile S, Profile G, Profile T),Http API
|
|
On-Board Storage
|
Built-in memory card slot, supports micro SD/SDHC/SDXC card, up to 256 GB
|
|
Audio
|
1 Input, 1 Output
|
|
Alarm
|
1 input, 1 output
|
|
Simultaneous
|
Live View Up to 15 channels
|
|
Protection
|
IP66
|
|
Operating Conditions
|
-40 °C to 60 °C (-22 °F to 149 °F) Humidity 90% or less (non-condensing)
|
|
Material
|
Metal
|
|
Dimensions
|
Ø 160 mm × 270 mm (Ø 6.3” × 10.6”)
|
|
Weight
|
Approx 2.5 kg (5.51lb.)
|
|
Power
|
DC 12V/POE+, max. 22 W
|
|
Reset
|
Yes
|
|
Ethernet Interface
|
1 RJ45 10M/100M self-adaptive Ethernet port
|
|
Built-In Speaker
|
NA
|
|
User/Host
|
5 User
|
|
Security
|
Password protection, complicated password, HTTPS encryption, IP address filter,control timeout settings
|
|
Client
|
VMS
|
|
Web Browser
|
IE10/11, Safari V12.1 above, Firefox V.52 above, Google chrome V.57 above, Edge V.79 above
|
|
Basic Event
|
Motion detection, alarm input and output
|
|
Deep Learning Function
|
Face Recognition, Human & Vehicle Detection, Perimeter Intrusion Detection, Line Crossing Detection, Stationary Object Detection, Crossing Counting, Heat Map, Crowd Density Detection, Queue Length Detection, License Plate Detection
|
|
Smart Tracking
|
auto-tracking
|
|
Alarm Linkage
|
Upload to FTP, send email, trigger alarm output, trigger recording
|
True WDR
