- Imaging Sensor
- 1/2.8” Progressive Scan CMOS
- Max. Resolution
- 1920x1080
- Min. Illumination
- 0.002 Lux @ (F1.6, AGC ON), B/W
- Shutter Speed
- 1/5 s to 1/20000 s
- Slow Shutter
- Yes
- Day & Night
- IR cut filter
- Zoom
- 25x optical
- Focal Length
- 5.0 mm to 125 mm
- FOV
- 56.9° to 2.9° (wide-tele) Vertical field of view
- Aperture
- Max. F1.5
- Focus
- Auto,manual
- Supplement Light Range
- up to 100 m
- Supplement Light Type
- IR and Warm Light
- Movement Range(PAN)
- 360°
- Movement Range(TILT)
- -10° to 90° (auto flip)
- Pan Speed
- configurable from 0.6° to 80°/s; preset speed
- Tilt Speed
- configurable from 0.6° to 80°/s; preset speed
- Presets
- 255
- Patrol Scan
- 1 Scan
- Pattern Scan
- 4 pattern
- Power-Off Memory
- Yes
- 3D Positioning
- Yes
- Day/Night Switch
- Day, Night, Auto, Schedule
- Image Enhancement
- BLC, HLC, 3D DNR
- Wide Dynamic Range (WDR)
- 120 dB
- Defog & Image Stabilization
- Digital
- Image Settings
- Saturation, brightness, contrast, sharpness, Hue and white balance adjustable by client software or web browser
- Privacy
- 4 Privacy Masks
- Main Stream
- 25 fps (1920 × 1080, 1280 × 960, 1280 × 720); 60 Hz
- Sub-Stream
- 25 fps (640 × 480, 320x240); 60 Hz
- Third Stream
- 25 fps (320x240); 60 Hz
- Video Compression
- H.265+/H.265/H.264+/H.264 Sub-stream
- Video Bit Rate
- 8 kbps to 8192 kbps
- H.264 TYPE
- Baseline Profile/Main Profile/High Profile
- H.265 TYPE
- Main Profile
- Region Of Interest (ROI)
- NA
- Audio Compression
- G.711a/G.711u
- Protocols
- IPv4/IPv6, HTTP, HTTPS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, TCP/IP, UDP, DHCP, PPPoE,
- API
- Onvif ( Profile S, Profile G, Profile T),Http API
- On-Board Storage
- Built-in memory card slot, supports micro SD/SDHC/SDXC card, up to 256 GB
- Audio
- 1 Input, 1 Output
- Alarm
- 1 input, 1 output
- Simultaneous
- Live View Up to 15 channels
- Protection
- IP66
- Operating Conditions
- -40 °C to 60 °C (-22 °F to 149 °F) Humidity 90% or less (non-condensing)
- Material
- Metal
- Dimensions
- Ø 160 mm × 270 mm (Ø 6.3” × 10.6”)
- Weight
- Approx 2.5 kg (5.51lb.)
- Power
- DC 12V/POE+, max. 22 W
- Reset
- Yes
- Ethernet Interface
- 1 RJ45 10M/100M self-adaptive Ethernet port
- Built-In Speaker
- NA
- User/Host
- 5 User
- Security
- Password protection, complicated password, HTTPS encryption, IP address filter,control timeout settings
- Client
- VMS
- Web Browser
- IE10/11, Safari V12.1 above, Firefox V.52 above, Google chrome V.57 above, Edge V.79 above
- Basic Event
- Motion detection, alarm input and output
- Deep Learning Function
- Face Recognition, Human & Vehicle Detection, Perimeter Intrusion Detection, Line Crossing Detection, Stationary Object Detection, Crossing Counting, Heat Map, Crowd Density Detection, Queue Length Detection, License Plate Detection
- Smart Tracking
- auto-tracking
- Alarm Linkage
- Upload to FTP, send email, trigger alarm output, trigger recording
