- Imaging Device
- 1/2.7”
- Effective Pixels
- 5MP 2880(H) x1620(V)
- Scanning System
- Progressive CMOS
- Min. Illumination
- Color 0.004lux @ F1.6(AGC ON) ; B/W 0 lux @ IR ON
- Focal Length (Zoom Ratio)
- 2.8 mm
- Max. Aperture Ratio
- F No. 2.8
- Angular Field Of View
- 96°, Vertical
- Min. Object Distance
- 0.3m~∞
- Lens Type
- Fixed(M12)
- IR Viewable Length
- NA
- Camera Title
- On/Off
- Backlight Compensation
- Off/On (5 Zones)
- Wide Dynamic Range
- WDR
- Digital Noise Reduction
- 3D DNR
- Motion Detection
- Off/On (8 Levels)
- Privacy Masking
- Off/On (4 Zones, Rectangle)
- Gain Control
- Auto
- White Balance
- Auto/Manual
- Electronic Shutter Speed
- 1/5 ~ 1/20000s
- On-Board Storage
- NA
- Alarm
- NA
- Audio
- 1 Input, 1 Output
- Hardware Reset
- Yes
- AI Features
- Face Detection, Pedestrian & Vehicle , Perimeter Intrusion , Line Crossing, Object Detection, Crossing Counting, Heat Map, Crowd Density , Queue Length, License Plate, Rare Sound, Intrusion, Region Entrance, Region Exiting
- Ethernet
- RJ45(10/100BASE-T)
- Video Compression Format
- H.265/H.264
- Resolution
- Main Stream@30fps 5MP(2880x1620),4MP(2560x1440) 3MP(2304x1296),1080P(1920x1080) 720P(1280x720) Sub Stream@30fps 720P(1280x720),VGA(640x480),QVGA(320x240) Mobile Stream@30fps VGA(640x480), QVGA(320x240)
- Video Quality Adjustment
- 256Kbps ~ 8Mbps
- Bitrate Control Method
- CBR/VBR
- Streaming Capability
- Triple-Stream(Main/Sub/Mobile)
- Protocol
- TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP, SMTP,NTP,UPnP,SNMP,HTTPS,FTP
- Web Browser
- IE10/11, Safari V12.1 above, Firefox V.52 above Google chrome V.57 above, Edge V.79 above
- Security
- IP address filter; complicated password; Authenticated username and password
- Streaming Method
- Unicast/Multicast
- Application Programming Interface
- ONVIF( Profile S/G/T)
- Operating Conditions
- -35~+60°C/less than ≤ 90% RH
- Input Voltage / Current
- D12V/POE(IEEE802.3af)
- Material
- Metal
- Color
- BLACK
