New
8MP Resolution
PRODUCT SPECIFICATIONS
| Imaging Device | 1/1.8'' |
| Effective Pixels | 8MP 3840(H)×2160(V) |
| Scanning System | Progressive CMOS |
| Min. Illumination | 0.0008 Lux @ (F1.7, AGC ON);0 Lux with IR |
| Focal Length (Zoom Ratio) | 8-32mm (fast zoom) |
| Max. Aperture Ratio | F1.7 to F 1.76 |
| Angular Field Of View | 40(W)-14(T)° V |
| Min. Object Distance | 1.5 m ~ INF, T |
| IRIS Type | Precise iris |
| IR LED | 8 |
| Warmlight | 4 |
| IR Viewable Length | Up to 100m |
| Warmlight Viewable Length | Up to 30m |
| Type Of Complementary Light | Default warm light, switchable infrared light |
| Motion Detection | Off/On (8 Levels) |
| Wide Dynamic Range | 120dB |
| Digital Noise Reduction | 3D DNR |
| Image Setting | Full Color Mode/Day&Night Mode/Smart IIIumination |
| White Balance | Auto/Manual |
| Electronic Shutter Speed | 1/5 ~ 1/20000s |
| On-Board Storage | Micro SD slot, up to 1TB |
| Alarm | 2 inputs, 2 outputs |
| Audio | 1 in / 1 out |
| DUAL MODES | Customizable Voice |
| DUAL Light Sources | 24/7 All-weather Color Images |
| Custom Voice | Yes |
| Hardware Reset | Yes |
| Smart Features | Rare Sound Detection (SD) , Perimeter Intrusion Detection (PID), Face Detection (FD), Stationary Object Detection (SOD), Crowd Density Detection (CD), Human&Vehicle Detection (PD&VD), Line Crossing Detection (LCD), Queue Lenght Detection (QD), Heat Map (HM), Cross Counting (CC), License Plate Detection (LPD), Region Entrance and Exiting (RE), Intrusion, Noise Detection |
| LPR Vehicle Speed | Up to 120km/h |
| Ethernet | RJ45(10/100BASE-T) |
| Video Compression Format | H.265/H.264/ H.265+/H.264+ |
| Resolution | 8MP |
| Video Bit Rate | 256Kbps ~ 16Mbps |
| Bitrate Control Method | CBR/VBR |
| IP | IPv6 |
| Protocol | TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP, SMTP,NTP,UPnP,SNMP,HTTPS,FTP |
| Security | IP address filter;complicated password; Authenticated username and password |
| Application Programming Interface | ONVIF( Profil S/G/T) |
| Compatible Web Browsers | IE10/11, Safari V12.1/above, Firefox V.52/above, Google chrome V.57/above, Edge V.79/above |
| Operating Conditions | -35°~+60°C/less than ≤ 90% RH |
| Ingress Protection | IP67, IK10, NEMA 4X |
| Input Voltage / Current | D12V/POE (IEEE802.3af) |
| Power Consumption | max 10.24W; POE (48V) |
| Material | Metal |
| Dimensions (LXHXP) | 353.8mm×135.2mm |
DOWNLOAD
| DATA SHEET | |
| gsd-lprb9z832ip8mp-ai-octavue-bullet-8mp-ip-network-camera-datasheet.pdf | Download |
| USER MANUAL | |
| manual-ipc-gsd-en.pdf | Download |
| manual-ipc-gsd-fr.pdf | Download |
| QUICK GUIDE | |
| gsd-ip-network-camera-octavue-guide-installation-rapide.pdf | Download |
| gsd-ip-network-camera-octavue-quick-installation-guide.pdf | Download |
