Bandwidth up to 100Mbps
PRODUCT SPECIFICATIONS
| Power Input | DC 48V-56V Adaptor PoE INPUT |
| PoE Supply To Camera | Max 30W, Standard PoE, IEEE802.3 af/at Mode A |
| Power Consumption | Max. 1W (No-load Condition) |
| Max. Distance Between Camera And IPCOAX-300M | Max. 500m(RG-6) / 400m(RG-59) (Full Duplex) |
| Camera Connection Port | 1x4 RJ-45 1Port (TIA/EIA568B Type) |
| NVR Connection Port | RJ-45 1Port (TIA/EIA568B Type) |
| EoC Connection Port | BNC-F 1Port , 75Ω |
| Connection Port Power | DC JACK 2.0 |
| RJ-45 Connector Pin Assignment (Polarity) | TX(+), PWR(+), 2Pin |
| Max. Transmission Bandwidth | 10/100Mbps(Full duplex) |
| Temperature/Humidity | -10°C ~ +50°C / 0 ~ 80% |
| Case Body/Weight | Aluminum / 326g |
| Dimensions(mm) | 159(W) x 92.5(H) x 34.7(D) |
