- Power Input
- DC 48V-56V Adaptor PoE INPUT
- PoE Supply To Camera
- Max 30W, Standard PoE, IEEE802.3 af/at Mode A
- Power Consumption
- Max. 1W (No-load Condition)
- Max. Distance Between Camera And IPCOAX-300M
- Max. 500m(RG-6) / 400m(RG-59) (Full Duplex)
- Camera Connection Port
- 1x4 RJ-45 1Port (TIA/EIA568B Type)
- NVR Connection Port
- RJ-45 1Port (TIA/EIA568B Type)
- EoC Connection Port
- BNC-F 1Port , 75Ω
- Connection Port Power
- DC JACK 2.0
- RJ-45 Connector Pin Assignment (Polarity)
- TX(+), PWR(+), 2Pin
- Max. Transmission Bandwidth
- 10/100Mbps(Full duplex)
- Temperature/Humidity
- -10°C ~ +50°C / 0 ~ 80%
- Case Body/Weight
- Aluminum / 326g
- Dimensions(mm)
- 159(W) x 92.5(H) x 34.7(D)
