Power Input
|
DC 48V-56V/1A adapter or PoE Hub (IEEE 802.3at)
|
|
Power Output
|
PoC (DC 48V)
|
|
Power Consumption
|
DC 48V~56V/900mA (optional)
|
|
Max. Transmission Distance
|
500m, 50Mbps
|
|
Transmission Speed
|
100Mbps
|
|
Connection Port
|
TRANSMITTER SIDE - BNC-F, 75Ω NVR SIDE - RJ-45 (TIA/EIA568B Type) (DC 48V-56V IN - DC-JACK
|
|
LED Indicator
|
PWR - RED LED ETH - GREEN LED LINK - GREEN LED PoE - RED LED
|
|
Bandwidth Select Switch
|
10Mbps, 100M
|
|
Temperature/Humidity
|
-10°C ~ 50°C / 0 ~ 80%
|
|
Case Body/Weight
|
ABS / 62g
|
|
Dimensions
|
90(W) x 55(H) x 24(D)
|
|
Power Input
|
PoC
|
|
Power Output
|
Midspan PoE (Type B Only, PoE SW On/Off available)
|
|
Transmission Speed
|
100Mbps
|
|
Connection Port
|
RECEIVER SIDE - BNC-F, 75Ω CAMERA SIDE - RJ-45 (TIA/EIA568B Type)
|
|
LED Indicator
|
PWR - RED LED ETH - GREEN LED LINK - GREEN LED PoE - RED LED
|
|
Camera POE SW
|
Slide Switch
|
|
Temperature/Humidity
|
-10°C ~ 50°C / 0 ~ 80%
|
|
Case Body/Weight
|
ABS / 60g
|
|
Dimensions
|
90(W) x 55(H) x 24(D)
|
Transmit up to 20 IP Cameras
