Resolution
|
12MP, 8MP, 5MP, 3MP, 2MP(1080P), 1.3MP(960P), 1.0MP(720P)
|
|
Input
|
640M
|
|
Out
|
640M
|
|
Compression
|
G.711A/G.711U Video
|
|
AI Features
|
Yes
|
|
Frame Rate
|
240fps | 4MP
|
|
Event
|
MD (Sensitivity Level 1~8) Videlo loss | Beep, Email, Push notification to Mobile APP
|
|
Playback Function
|
Fast forward / backward (2x, 4x, 8x,16X) Slow forward (1/2x, 1/4x, 1/8x,1/16x)
|
|
Playback
|
Max 16CH playback
|
|
Raid Type
|
RAID0, RAID1, RAID5, RAID6, RAID10
|
|
Fisheye
|
Support Dewarping
|
|
Local
|
UI5.0
|
|
Web
|
IE10/11 Safari V12.1 above Firefox V.52 above Google chrome V.57 above Edge V.79 above
|
|
Mobile Viewer
|
SMART GUARDIAN
|
|
Push Notifications
|
Yes
|
|
P/W Reset
|
Yes
|
|
HDMI 1
|
3 (1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 , 1920*1080 , 1600*1200, 1920*1200, 3840*2160/7680*4320/EDID) Async out
|
|
HDMI 2
|
1 (1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 /EDID) Async out
|
|
Ethernet
|
2 RJ45 1000 Base-T
|
|
USB
|
USB2.0*1(front) USB3.0*2(rear)
|
|
Audio Out
|
1
|
|
E-SATA
|
1
|
|
HDD
|
8 SATA HDD, up to 16TB (WD Purple)
|
|
Line-In
|
1
|
|
RS232
|
1*RJ45
|
|
RS485
|
1
|
|
Alarm Input/Out
|
16in /4out
|
|
OSD Language
|
ENG/FR/SPA/PT/GER/IT/GR/DAN/FIN/RUS/HEB/ TUR/BUL/ARA/KOR/JPN/TH/HIN/ROM/DUT/POL
|
|
Dimension (WXHXD)
|
440*460*89mm
|
|
Input Voltage / Current
|
ATX 250W
|
|
Power Consumption
|
8W (Excluding hard disk)
|
|
Operating Temperature/Humidity
|
-10°C~+50°C (14°F ~ 122°F) Humidity
|
|
AI Features
|
HUMAN & VEHICLE DETECTION STATIONARY OBJECT DETECTION LICENSE PLATE DETECTION HEAT MAP CROWD DENSITY DETECTION NOISE DETECTION VIDEO TAMPERING CROSS COUNTING INTRUSION DETECTION REGION ENTRANCE & EXITING QUEUE LENGTH DETECTION AI REGISTERED QUANTITY 10,000 INSTANT NOTIFICATIONS AI MAX CAPTURED QUANTITY 200,000 PERIMETER INTRUSION DETECTION LINE CROSSING DETECTION FACE DETECTION RARE SOUND DETECTION
|
|
Hard Drive PURPLE
|
NO PURPLE HDD
,
16TB
,
24TB
,
32TB
,
64TB
,
96TB
|
|
Hard Drive GOLD
|
NO GOLD HDD
,
16TB-R
,
24TB-R
,
32TB-R
,
64TB-R
,
96TB-R
|
ONVIF Compliant (G/M/S/T)
