- Input
- 16Mbps
- Out
- 216Mbps
- Analog-Video-Input
- 32CH inputs
- IP Video Input
- 4ch
- Composite Video Input
- up to 36ch (Analog video + IP video)
- Compression
- G.711a Video
- Display Resolution
- 5MP-Lite (3.9MP)
- Speed
- 5MP-Lite
- AI Features
- PID - Perimeter Intrusion Detection LCD - Line Crossing Detection PD&VD - Human&Vehicle Detection FD - Face Detection FR - Face Recognition
- Event
- MD (Sensitivity Level 1~8) VIDEO LOSS Beep, Email, Push notification to Mobile APP
- Playback Function
- Fast forward / backward (2x, 4x, 8x,16X) Slow forward (1/2x, 1/4x, 1/8x,1/16x)
- Playback
- 240fps (Max 16CH playback) 4MP-lite
- AI Features
- PERIMETER INTRUSION DETECTION FACE DETECTION LINE CROSSING DETECTION STATIONARY OBJECT DETECTION* HUMAN & VEHICLE DETECTION CROWD DENSITY DETECTION* LICENSE PLATE DETECTION* RARE SOUND DETECTION* NOISE DETECTION* QUEUE LENGTH DETECTION* VIDEO TAMPERING* AI MAX CAPTURED QUANTITY 200,000 AI REGISTERED QUANTITY 10,000 *THESE AI FEATURES ONLY WORK WITH IP CAMERAS, OR ANALOG CAMERAS WITH 2MP OR MORE
- Local
- UI5.0
- Web
- IE10/11 / Safari V12.1 above / Firefox V.52 above Google chrome V.57 above / Edge V.79 above
- Mobile Viewer
- SMART GUARDIAN
- Push Notifications
- Yes
- P/W Reset
- Press 10 seconds
- BNC
- 1 (704*576)
- VGA
- 1(1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080)
- HDMI
- 1(1024*768,1280*720,1280*1024,1440*900,1920*1080,25 60*1440(2K),3840*2160(4K))
- Ethernet
- 2 RJ45 100/1000 Base-T
- USB
- USB2.0*1(front) / USB3.0*1+(rear)
- Audio
- 8 in /1 out
- HDD
- 4 SATA HDD, Up to 16 TB capacity for each disk
- E-SATA
- 1
- RS485
- 1
- Alarm Input/Out
- 16 in /1 out
- OSD Language
- English/French/Spanish/Portuguese/German/ Italian/Greek/Danish/Finnish/Russia/Hebrew/ Turkish/Bulgarian/Arabic/Korean/Japanese/ Thai/Hindi/Romanian/Dutch/Polish
- Dimension (WXHXD)
- 380*340*50mm
- Input Voltage / Current
- DC12V/5A
- Power Consumption (Excluding Hard Disk)
- 21W
- Operating Temperature/Humidity
- -10°C~+50°C (14°F ~ 122°F) Humidity
- Hard Drive PURPLE
- NO PURPLE HDD, 8TB, 16TB, 24TB
