Imaging Device
|
1/1.6”
|
|
Effective Pixels
|
12MP 3536(H)×3536(V)
|
|
Min. Illumination
|
Color 0.009lux @ F1.6(AGC ON) ; B/W 0 lux @ IR ON
|
|
Scanning System
|
Progressive CMOS
|
|
Focal Length (Zoom Ratio)
|
2.0mm
|
|
Max. Aperture Ratio
|
F No. 2.8
|
|
Angular Field Of View
|
horizontal FOV 180° (wall mount), 360° (ceiling mount)
|
|
Lens Type
|
Fixed(M12)
|
|
IR LED
|
3
|
|
IR Viewable Length
|
Up to 10m
|
|
Motion Detection
|
Off/On (8 Levels)
|
|
Wide Dynamic Range
|
WDR
|
|
Digital Noise Reduction
|
3D DNR
|
|
Day & Night
|
IR cut filter with auto switch (Day/Night/Auto/Image/Schedule)
|
|
White Balance
|
Auto/Manual
|
|
Electronic Shutter Speed
|
1/5 ~ 1/20000s
|
|
On-Board Storage
|
Micro SD slot, up to 1TB
|
|
Alarm
|
1 input, 1 output
|
|
Audio
|
Built-in microphone & speaker
|
|
Custom Voice
|
Yes
|
|
Hardware Reset
|
Yes
|
|
AI Features
|
Line Crossing, Crossing Counting, Heat Map, Rare Sound, Intrusion, Region Entrance, Region Exiting, Queue Length, Crowd Density
|
|
Ethernet
|
RJ45(10/100BASE-T)
|
|
Video Compression
|
H.265/H.265+/H.264/H.264+MJPEG
|
|
Resolution
|
Mainstream@30fps 12MP (3536x3536), 3000x3000, 2560x2560, 2160x2160, 1520x1520, 1080x1080, 720x720 Substeam@30fps 2MP (1080x1080), 720x720, 480x480, 240x240
|
|
Video Quality Adjustment
|
256Kbps ~ 16Mbps
|
|
Bitrate Control Method
|
CBR/VBR
|
|
IP
|
IPv6
|
|
Protocol
|
TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP, SMTP,NTP,UPnP,SNMP,HTTPS,FTP
|
|
Security
|
IP address filter; complicated password; Authenticated username and password
|
|
Application Programming Interface
|
ONVIF( Profile S/G/T/M)
|
|
Web Viewer
|
IE10/11, Safari V12.1 above, Firefox V.52 above Google chrome V.57 above, Edge V.79 above
|
|
Operating Conditions
|
-35°+60°C/ Less than ≤ 95% RH
|
|
Ingress Protection
|
IP66
|
|
Input Voltage / Current
|
D12V/POE (IEEE802.3af)
|
|
Material
|
Metal
|
12MP Resolution
