- Imaging Device
- 1/1.6”
- Effective Pixels
- 12MP 3536(H)×3536(V)
- Min. Illumination
- Color 0.009lux @ F1.6(AGC ON) ; B/W 0 lux @ IR ON
- Scanning System
- Progressive CMOS
- Focal Length (Zoom Ratio)
- 2.0mm
- Max. Aperture Ratio
- F No. 2.8
- Angular Field Of View
- horizontal FOV 180° (wall mount), 360° (ceiling mount)
- Lens Type
- Fixed(M12)
- IR LED
- 3
- IR Viewable Length
- Up to 10m
- Motion Detection
- Off/On (8 Levels)
- Wide Dynamic Range
- WDR
- Digital Noise Reduction
- 3D DNR
- Day & Night
- IR cut filter with auto switch (Day/Night/Auto/Image/Schedule)
- White Balance
- Auto/Manual
- Electronic Shutter Speed
- 1/5 ~ 1/20000s
- On-Board Storage
- Micro SD slot, up to 1TB
- Alarm
- 1 input, 1 output
- Audio
- Built-in microphone & speaker
- Custom Voice
- Yes
- Hardware Reset
- Yes
- AI Features
- Line Crossing, Crossing Counting, Heat Map, Rare Sound, Intrusion, Region Entrance, Region Exiting, Queue Length, Crowd Density
- Ethernet
- RJ45(10/100BASE-T)
- Video Compression
- H.265/H.265+/H.264/H.264+MJPEG
- Resolution
- Mainstream@30fps 12MP (3536x3536), 3000x3000, 2560x2560, 2160x2160, 1520x1520, 1080x1080, 720x720 Substeam@30fps 2MP (1080x1080), 720x720, 480x480, 240x240
- Video Quality Adjustment
- 256Kbps ~ 16Mbps
- Bitrate Control Method
- CBR/VBR
- IP
- IPv6
- Protocol
- TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP, SMTP,NTP,UPnP,SNMP,HTTPS,FTP
- Security
- IP address filter; complicated password; Authenticated username and password
- Application Programming Interface
- ONVIF( Profile S/G/T/M)
- Web Viewer
- IE10/11, Safari V12.1 above, Firefox V.52 above Google chrome V.57 above, Edge V.79 above
- Operating Conditions
- -35°+60°C/ Less than ≤ 95% RH
- Ingress Protection
- IP66
- Input Voltage / Current
- D12V/POE (IEEE802.3af)
- Material
- Metal
