Bandwidth up to 100Mbps
PRODUCT SPECIFICATIONS
| POE Ports | 1 |
| Max. Digital Transmission Bandwidth | 100Mbps (Bandwidth Switch |
| Max. Self-Power Consumption | 2W |
| Power Input | PoE (Power over Ethernet) from SC-IPIR07PU |
| Power Output | Midspan PoE |
| Max. Power(POE) Supply | 30W |
| Max. Transmission Distance | 500m(100Mbps), 800m(10Mbps) |
| Temperature/Humidity | -10°C ~ +50°C / 0 ~ 80% |
| Connection Port | RJ-45 X 2 |
| Case Body/Weight | ABS / 52g |
| Dimensions(mm) | 76(W) x 55(H) x 24(D) |
| 100Mbps | 500m |
| 10Mbps | 800m |
| Max. Digital Transmission Bandwidth | 100Mbps (Bandwidth Switch |
| Max. Self-Power Consumption | 2W |
| Power Input | DC 48V~56V Adapter or PoE |
| Max. Power(POE) Supply | 30W |
| Max. Transmission Distance | 500m(100Mbps), 800m(10Mbps) |
| Temperature/Humidity | -10°C ~ +50°C / 0 ~ 80% |
| Connection Port | RJ-45 X 2 |
| Case Body/Weight | ABS / 54g |
| Dimensions(mm) | 76(W) x 55(H) x 24(D) |
