- POE Ports
- 2
- Chip Scheme
- RTL8305NB+SD4923E
- Standards/Protocols
- IEEE 802.3u, IEEE 802.1Q,IEEE 802.1p,IEEE 802.3af/at
- Network Media
- Unshielded Class 3,4 and 5 twisted pair (max 100m) 100BASE-TX/100BASE-T
- Joggle
- One 10/100/1000M RJ45 port (Auto Negotiation/Auto MDI/MDIX) One 10/100/1000M RJ45 port (Auto Negotiation/Auto MDI/MDIX) One 10/100M UP-LINK RJ45 port (Auto Negotiation/Auto MDI/MDIX)
- Cascade
- The output port is cascade
- Forward Mode
- Store-and-forward
- Mac Address
- Empty amount 1K
- Exchange Capacity
- 0.6Gbps
- Package Forwarding Rate
- 0.447Mpps
- Package Cache
- 768 Kbits
- Giant Frame
- 2048 bytes
- POE Input/Output Port
- Supports 4 core / 8 core power supply
- Power Pin
- 1/2 ,4/5 (+) 3/6, 7/8 (-)
- POE Port Output Power
- 30W
- Quiescent Dissipation
- 0.2W
- Working Temperature
- -10°C~ 70°C (32°F~127°F)
- Storage Temperature
- -40°C~85°C (-97°F~142°F)
- Working Humidity
- 10%~90% noncondensing
- Store Humidity
- 5%~95% noncondensing
- Housing Material
- Metal Case
