- Imaging Device
- 1/2.7” CMOS (SC4653 )
- Effective Pixels
- 5.0 Mega Pixels
- Scanning System
- progressive scanning
- Electronic Shutter Speed
- 1/25s~1/50,000s , 1/30s~1/60,000s
- Min. Illumination (Day)
- Color 0.01Lux@F1.2
- Min. Illumination (Night)
- B/W 0.001 Lux@F1.2
- S/N Ratio
- More than 50dB (AGC OFF)
- IR Distance
- 20M
- IR ON/OFF Control
- Auto
- IR LEDS
- 18 pieces IR LEDs
- Lens Type
- 2.8mm
- Mount Type
- Fixed
- Focal Length
- No
- Max. Aperture
- F2.0
- Angle Of View
- 120°
- Focus Control
- No
- Video Signal
- TVI / AHD / CVI / 960H
- Resolution
- 2592*1944
- Frame Rate
- 25/30fps
- Video Output
- BNC
- Day/Night
- Yes
- OSD Menu
- Yes
- BLC Mode
- Yes
- WDR
- DWDR
- Gain Control
- AGC
- Noise Reduction
- 3D
- White Balance
- Auto
- Smart IR
- Yes
- Audio Interface
- No
- Power Supply
- DC12V
- Power Consumption
- 600mA max., IR Off
- Operating Conditions
- -10°C ~ +50°C RH95% Max
- Storage Conditions
- 20°C ~ +60°C RH95% Max
- Material
- Metal
- Dimensions
- 92mmx64mm
- Weight
- 360g
