Resolution
|
8MP,5MP, 3MP ,2MP(1080P),1.3MP(960P),1.0MP(720P)
|
|
Input
|
50Mbps
|
|
Out
|
64Mbps
|
|
Installation Wizard
|
Yes
|
|
Compression
|
G.711a Video
|
|
AI Features
|
Yes
|
|
Decoding Resources
|
1ch 4K(main stream), if more than 1 4K camera are connected, it will be switched to sub stream. Playback
|
|
Frame Rate
|
30fps 4MP
|
|
Event
|
MD (Sensitivity Level 1~8) Videlo loss Beep, Email, Push notification to Mobile APP
|
|
Playback Function
|
Fast forward / backward (2x, 4x, 8x,16X) Slow forward (1/2x, 1/4x, 1/8x,1/16x)
|
|
Playback
|
Max 4CH playback
|
|
AI Features
|
HUMAN & VEHICLE DETECTION STATIONARY OBJECT DETECTION LICENSE PLATE DETECTION HEAT MAP CROWD DENSITY DETECTION NOISE DETECTION VIDEO TAMPERING CROSS COUNTING INTRUSION DETECTION REGION ENTRANCE & EXITING QUEUE LENGTH DETECTION AI REGISTERED QUANTITY 10,000 INSTANT NOTIFICATIONS AI MAX CAPTURED QUANTITY 200,000 PERIMETER INTRUSION DETECTION LINE CROSSING DETECTION FACE DETECTION RARE SOUND DETECTION
|
|
Local
|
UI5.0
|
|
Web
|
IE10/11, Safari V12.1 above, Firefox V.52 above Google chrome V.57 above, Edge V.79 above
|
|
Mobile Viewer
|
SMART GUARDIAN
|
|
Push Notifications
|
Yes
|
|
P/W Reset
|
Press 10 seconds After the button press and the buzzer beeps, it means the reset is done.
|
|
VGA
|
1 (1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080)
|
|
HDMI
|
1 (1024*768, 1280*720, 1280*1024,1440*900, 1920*1080 , 2560*1440, 3840*2160/EDID
|
|
POE
|
4 POE
|
|
Ethernet
|
1 RJ45 10/100 Base-T
|
|
USB
|
USB2.0*1(front) USB2.0*1+(rear)
|
|
Audio Out
|
1
|
|
E-SATA
|
No
|
|
HDD
|
The recorder can support up to 16TB
|
|
Line-In
|
No
|
|
RS485
|
No
|
|
Alarm Input/Out
|
No
|
|
OSD Language
|
EN/FR/ES/DN/TC/IN/JP/KR
|
|
Dimension (WXHXD)
|
300X208X53mm
|
|
Input Voltage / Current
|
DC48V/1.2A | PoE Swith
|
|
Power Consumption
|
4W
|
|
Operating Temperature/Humidity
|
0°C~+40°C (32°F ~ 104°F) Humidity
|
UP TO 8MP
