Spot Monitor out on BNC
PRODUCT SPECIFICATIONS
| Inputs | 16Mbps ~80Mbps Analog channel and digital channel can be converted Encoding performance and decoding performance cannot be converted Total decoding performance 1080P 120fps |
| Out | 96Mbps |
| Analog-Video-Input | 16CH inputs |
| IP Video Input | 4ch,(only IP up to 20ch) |
| Composite Video Input | Up to 20ch (Analog video + IP video) |
| Installation Wizard | Yes |
| Compression | G.711a / Video |
| Display Resolution | 5MP-Lite (3.9MP) |
| Speed | 5MP-Lite |
| Event | MD (Sensitivity Level 1~8) Videlo loss Beep, Email, Push notification to Mobile APP |
| Playback Function | Fast forward / backward (2x, 4x, 8x,16X) Slow forward (1/2x, 1/4x, 1/8x,1/16x) |
| Playback | 96fps (Max 8CH playback), 4MPlite |
| AI Features | PERIMETER INTRUSION DETECTION FACE DETECTION LINE CROSSING DETECTION STATIONARY OBJECT DETECTION* HUMAN & VEHICLE DETECTION CROWD DENSITY DETECTION* LICENSE PLATE DETECTION* RARE SOUND DETECTION* NOISE DETECTION* QUEUE LENGTH DETECTION* VIDEO TAMPERING* AI MAX CAPTURED QUANTITY 200,000 AI REGISTERED QUANTITY 10,000 *THESE AI FEATURES ONLY WORK WITH IP CAMERAS, OR ANALOG CAMERAS WITH 2MP OR MORE |
| Local | UI5.0 |
| Web | IE10/11 / Safari V12.1 above / Firefox V.52 above Google chrome V.57 above / Edge V.79 above |
| Mobile Viewer | SMART GUARDIAN |
| Push Notifications | Yes |
| Voice Command | Google Assistant, Amazon Alexa |
| P/W Reset | Yes |
| BNC | 1 (704*576) |
| VGA | 1 (1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080) |
| HDMI | 1 (1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080, 2560*1440(2K) ,3840*2160(4K)) |
| Ethernet | 2 RJ45 100/1000 Base-T |
| USB | USB2.0*1 (front) USB3.0*1+ (rear) |
| Audio | 16 in / 1 out (4 in /1 out optional) |
| E-SATA | 1 |
| HDD | 2 SATA HDD, up to 16TB |
| RS485 | 1 |
| Alarm Input/Out | 16 in /1 out optional |
| OSD Language | EN/FR/ES/DN/TC/IN/JP/KR |
| Dimension (WXHXD) | 378*326*66mm |
| Input Voltage / Current | DC12V/2A 2HDD |
| Power Consumption (Excluding Hard Disk) | TBD |
| Operating Temperature/Humidity | -10°C~+50°C (14°F ~ 122°F) Humidity |
