Color
|
BLACK
|
|
Imaging Sensor
|
1/2.7” Progressive Scan CMOS
|
|
Image Size
|
5MP 1944(H)×2592(V)
|
|
Electronic Shutter Speed
|
1/5 ~ 1/20000s
|
|
IRIS Type
|
Fixed IRIS
|
|
Min. Illumination
|
0 lux (white LED ON)
|
|
Lens
|
Vertical
|
|
Lens Mount
|
M8
|
|
Wide Dynamic Range (WDR)
|
Yes
|
|
BLC Mode
|
Yes
|
|
HLC
|
Yes
|
|
Video Compression
|
H.265/H.264/MJPEG
|
|
H.264 COMPRESSION STANDARD
|
Baseline Profile/Main Profile/High Profile
|
|
Video Bit Rate
|
256Kbps ~ 6Mbps
|
|
Bit Rate Type
|
VBR/CBR
|
|
Max. Resolution
|
1944 x 2592, 1800 x 2400, 960 x 1280
|
|
Main Stream
|
20fps @ 1944 x 2592,1800 x 2400 (Default)
|
|
Sub-Stream
|
20fps @ 960 x 1280
|
|
Image Settings
|
Saturation, hue, brightness, contrast, sharpness, 3DNR
|
|
Audio Compression
|
G711A, G711U
|
|
Network Interface
|
100M Rj45
|
|
Audio Interface
|
Built-in MIC×1, built-in speaker×1
|
|
Reset Button
|
Yes
|
|
On-Board Storage
|
1CH built-in micro SD card slot, up to 512GB
|
|
WIFI
|
Supports 2.4G/5G WiFi
|
|
Doorbell Button
|
Yes
|
|
Indicator
|
Yes
|
|
Remote Monitoring
|
Web client/CMS remote control/Moblie App
|
|
Online Connection
|
Supports simultaneous monitoring for up to 5 users Supports multi-stream real time transmission
|
|
Network Protocol
|
UDP , IPv4, DHCP , NTP , RTSP , DDNS, SMTP , UPnP , HTTPS, HTTP
|
|
Interface Protocol
|
ONVIF
|
|
AI Features
|
Human Detection, Package Detection, Loitering Detecion
|
|
General Function
|
Video mask, Motion
|
|
White Light Distance
|
1m
|
|
IR Light Distance
|
3m
|
|
Ingress Protection
|
IP65
|
|
Power
|
AC/DC 16-24V
|
|
POE Power
|
Yes
|
|
Power Consumption
|
Max. 9.84W
|
|
Environment
|
less than 90% (non-condensing)
|
|
Dimensions(mm)
|
146x46x30mm (5.75”x1.81”x1.18”)
|
|
Net Weight
|
115.3g
|
|
Installation
|
Wall Mounted
|
|
Input Voltage / Current
|
AC 100~240 V; 50~60 Hz
|
|
Transmission Mode
|
RF 433 Mhz
|
|
Button
|
Seting up/Selecting ringtones/Adjusing volume
|
|
SD Card
|
64GB Micro SD Card Included
|
|
NUMBER OF RELAYS
|
1
|
5MP Resolution
