- Color
- BLACK
- Imaging Sensor
- 1/2.7” Progressive Scan CMOS
- Image Size
- 5MP 1944(H)×2592(V)
- Electronic Shutter Speed
- 1/5 ~ 1/20000s
- IRIS Type
- Fixed IRIS
- Min. Illumination
- 0 lux (white LED ON)
- Lens
- Vertical
- Lens Mount
- M8
- Wide Dynamic Range (WDR)
- Yes
- BLC Mode
- Yes
- HLC
- Yes
- Video Compression
- H.265/H.264/MJPEG
- H.264 COMPRESSION STANDARD
- Baseline Profile/Main Profile/High Profile
- Video Bit Rate
- 256Kbps ~ 6Mbps
- Bit Rate Type
- VBR/CBR
- Max. Resolution
- 1944 x 2592, 1800 x 2400, 960 x 1280
- Main Stream
- 20fps @ 1944 x 2592,1800 x 2400 (Default)
- Sub-Stream
- 20fps @ 960 x 1280
- Image Settings
- Saturation, hue, brightness, contrast, sharpness, 3DNR
- Audio Compression
- G711A, G711U
- Network Interface
- 100M Rj45
- Audio Interface
- Built-in MIC×1, built-in speaker×1
- Reset Button
- Yes
- On-Board Storage
- 1CH built-in micro SD card slot, up to 512GB
- WIFI
- Supports 2.4G/5G WiFi
- Doorbell Button
- Yes
- Indicator
- Yes
- Remote Monitoring
- Web client/CMS remote control/Moblie App
- Online Connection
- Supports simultaneous monitoring for up to 5 users Supports multi-stream real time transmission
- Network Protocol
- UDP , IPv4, DHCP , NTP , RTSP , DDNS, SMTP , UPnP , HTTPS, HTTP
- Interface Protocol
- ONVIF
- AI Features
- Human Detection, Package Detection, Loitering Detecion
- General Function
- Video mask, Motion
- White Light Distance
- 1m
- IR Light Distance
- 3m
- Ingress Protection
- IP65
- Power
- AC/DC 16-24V
- POE Power
- Yes
- Power Consumption
- Max. 9.84W
- Environment
- less than 90% (non-condensing)
- Dimensions(mm)
- 146x46x30mm (5.75”x1.81”x1.18”)
- Net Weight
- 115.3g
- Installation
- Wall Mounted
- Input Voltage / Current
- AC 100~240 V; 50~60 Hz
- Transmission Mode
- RF 433 Mhz
- Button
- Seting up/Selecting ringtones/Adjusing volume
- SD Card
- 64GB Micro SD Card Included
