- IP Rating
- IP66
- Filter
- Removable IR Cut Filter
- Image Sensor
- 1/2.9” 2MP Progressive Scan CMOS
- Pixels
- 2688(H)×1944(V)
- Horizontal Resolution
- 2MP
- Lens
- 2.8mm Fixed
- IR Range
- 20 Meters
- Min. Illumination
- 0 Lux When IR ON
- Electronic Shutter
- 1/30-1/100,000s PAL
- Video Compression
- H.264 / H.265
- Transmission Stream Rate
- 36Kb~16M)
- Frame Rate
- 1~25fps (PAL) ,1~30fps (NTSC)
- Audio Compression
- G711A, G711U
- Network Interface
- RJ45*1 10M/100M
- Remote Control Interface
- /
- Audio Interface
- input/output*1
- Alarm Interface
- input/output*1
- Protocol
- TCP/IP, UDP, SMTP, PPPoE, DDNS, DHCP, FTP, RTSP, HTTP, IPv6
- Network Support
- ONVIF, API
- Users
- 10
- Web Language
- English, Simplified Chinese, Traditional Chinese
- Image Setting
- Contrast, Brightness, Sharpness, Saturation , WDR, 3DNR, HLC,BLC
- Storage
- NVR, VMS, TF Card
- Video Type
- Manual, Timing, Motion Detection, Face Detection
- Alarm Triggers
- Motion Detection, AI Face Detection
- Alarm Event
- Snapshot, Video, Alarm Output, Email Upload,
- System/Explorer Support
- IE, Chrome, Firefox, Safari
- General Function
- Flashing, Mirror, OSD information overlay, Camera angle, Banner
- Power Supply
- DC12V±10%, POE
- Current Consumption
- 770mA (Max)
- Dimensions
- 114x81.8mm (4.49”x3.22”)
- Weight
- 600g
- Storage Temperature
- -30° ~ +60°
- Operating Temperature
- -30° ~ +45°
