Imaging Device
|
1/2.3”
|
|
Effective Pixels
|
12MP 4096(H)×3072(V)
|
|
Scanning System
|
Progressive CMOS
|
|
Min. Illumination
|
Color 0.01lux @ F1.6(AGC ON) ; B/W 0 lux @ IR ON
|
|
Focal Length (Zoom Ratio)
|
3.6 mm
|
|
Max. Aperture Ratio
|
F No. 1.6
|
|
Angular Field Of View
|
87°, Vertical
|
|
Min. Object Distance
|
2m
|
|
Lens Type
|
Fixed (M12)
|
|
IR Viewable Length
|
Up to 30m
|
|
Camera Title
|
On/Off
|
|
Day & Night
|
IR cut filter with auto switch (Day/Night/Auto/Image/Schedule)
|
|
Backlight Compensation
|
Off/On (5 Zones)
|
|
Wide Dynamic Range
|
DWDR
|
|
Digital Noise Reduction
|
3D DNR
|
|
Motion Detection
|
Off/On (8 Levels)
|
|
Privacy Masking
|
Off/On (4 Zones, Rectangle)
|
|
Gain Control
|
Auto
|
|
White Balance
|
Auto/Manual
|
|
Electronic Shutter Speed
|
1/5 ~ 1/20000s
|
|
On-Board Storage
|
Micro SD slot, up to 1TB
|
|
Alarm
|
NA
|
|
Audio
|
Built-in microphone
|
|
Hardware Reset
|
Yes
|
|
AI Features
|
Face Recognition, Pedestrian & Vehicle , Perimeter Intrusion , Line Crossing , Object Detection, Crossing Counting, Heat Map, Crowd Density , Queue Length , License Plate, Rare Sound, Intrusion, Region Entrance, Region Exiting
|
|
Ethernet
|
RJ45(10/100BASE-T)
|
|
Video Compression Format
|
H.265/H.264
|
|
Resolution
|
12MP (4096x3072)@15fps, 8MP (3840x2160)@25fps, 5MP (2592x1944,3072x1728)@25fps, 4MP (2592x1520)@25fps, 3MP (2304x1296)@25fps, 1080P (1920x1080)@25fps Sub stream
|
|
Video Quality Adjustment
|
256Kbps ~ 16Mbps
|
|
Bitrate Control Method
|
CBR/VBR
|
|
Streaming Capability
|
Triple-Stream(Main/Sub/Mobile)
|
|
Protocol
|
TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,SMTP,NTP,UPnP,SNMP,HTTPS,FTP
|
|
Security
|
IP address filter;complicated password; Authenticated username and password
|
|
Streaming Method
|
Unicast/Multicast
|
|
Application Programming Interface
|
ONVIF( Profile S/G/T)
|
|
Operating Conditions
|
-35°~+60°C/less than ≤ 90% RH
|
|
Waterproof
|
IP67
|
|
Input Voltage / Current
|
D12V/POE(IEEE802.3af)
|
|
Material
|
Metal
|
|
Dimensions
|
115*91.6mm
|
|
Weight
|
appr 556g
|
3.6mm Lens
