- Imaging Device
- 1/2.7”
- Effective Pixels
- 5MP 2592(H)×1944(V)
- Scanning System
- Progressive CMOS
- Min. Illumination
- Color 0.05lux @ F1.2(AGC ON) ; B/W 0 lux @ IR ON
- Focal Length (Zoom Ratio)
- 2.8 mm
- Max. Aperture Ratio
- F No. 1.6
- Angular Field Of View
- 97°, Vertical
- Min. Object Distance
- 1.8m
- Lens Type
- Fixed M12
- IR Viewable Length
- Up to 30m
- Camera Title
- On/Off
- Day & Night
- IR cut filter with auto switch (Day/Night/Auto/Image/Schedule)
- Backlight Compensation
- Off/On (5 Zones)
- Wide Dynamic Range
- WDR
- Digital Noise Reduction
- 3D DNR
- Motion Detection
- Off/On (8 Levels)
- Privacy Masking
- Off/On (4 Zones, Rectangle)
- Type of IR
- Invisible IR LED 940nm
- Gain Control
- Auto
- White Balance
- Auto/Manual
- Electronic Shutter Speed
- 1/5 ~ 1/20000s
- On-Board Storage
- Micro SD slot, up to 1TB
- Alarm
- NA
- Audio
- Built-in microphone
- Hardware Reset
- Yes
- AI Features
- Face Recognition, Pedestrian & Vehicle , Perimeter Intrusion , Line Crossing , Object Detection, Crossing Counting, Heat Map, Crowd Density , Queue Length , License Plate, Rare Sound, Intrusion, Region Entrance, Region Exiting
- Ethernet
- RJ45(10/100BASE-T)
- Video Compression Format
- H.265/H.264
- Resolution
- Mainstream@30fps 5MP(2592×1944),4MP(2592x1520) 3MP(2304x1296),1080P(1920x1080) 960P(1280x960),720P(1280x720) Substeam@30fps 720P(1280x720),VGA(640x480),QVGA(320x240) Mobilestream@30fps VGA(640x480), QVGA (320x240)
- Video Quality Adjustment
- 8Kbps ~ 8Mbps
- Bitrate Control Method
- CBR/VBR
- Streaming Capability
- Triple-Stream(Main/Sub/Mobile)
- IP
- IPv4
- Protocol
- TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP, SMTP,NTP,UPnP,SNMP,HTTPS,FTP
- Security
- IP address filter;complicated password; Authenticated username and password
- Streaming Method
- Unicast/Multicast
- Max. User Access
- Max 7 (admin+user)
- Application Programming Interface
- ONVIF( Profile S/G/T)
- Compatible Web Browsers
- IE8,9,10,11, Chrome 44/lower, Firefox 51/lower, Safari 11/lower
- Operating Conditions
- -30~+55°C/less than ≤ 95% RH
- Storage Conditions
- -30°~+60°C/less than ≤ 95% RH
- Ingress Protection
- IP67
- Protection Rating
- IK10
- Input Voltage / Current
- D12V/POE (IEEE802.3af)
- Power Consumption (IR OFF)
- 2.5W/3.5W
- Power consumption (IR ON)
- 4W/5.5W
- Color/material
- White/Metal
- Dimension (WXHXD)
- Ø115x90.1mm
- Weight
- appr 570g
