- Imaging Device
- 1/1.8''
- Effective Pixels
- 4MP 2688(H) x1520 (V)
- Scanning System
- Progressive CMOS
- Min. Illumination
- Color 0.0005 Lux @ (F1.0, AGC ON) ; B/W 0 lux @ IR ON
- Focal Length
- 2.8 mm to 12 mm
- Max. Aperture Ratio
- F No. 1.2
- Angular Field Of View
- 110-40°, Vertical
- Min. Object Distance
- 1.75m, T
- Lens Type
- Motorized Ø16.7
- IR LED
- 4
- Warmlight
- 4
- IR Viewable Length
- Up to 30m
- Warmlight Viewable Length
- Up to 25m
- Type Of Complementary Light
- Default warm light, switchable infrared light
- Motion Detection
- Off/On (8 Level)
- Wide Dynamic Range
- WDR
- Digital Noise Reduction
- 3D DNR
- Image Setting
- Full Color Mode/Day&Night Mode/Smart IIIumination
- White Balance
- Auto/Manual
- Electronic Shutter Speed
- 1/5 ~ 1/20000s
- On-Board Storage
- Micro SD slot, up to 1TB
- Alarm
- IN/OUT
- Audio
- Built-in microphone & Speaker; 1 input (RCA), 1 output (RCA)
- Custom Voice
- Yes
- AI Features
- Face Detection, Pedestrian & Vehicle , Perimeter Intrusion , Line Crossing, Object Detection, Crossing Counting, Heat Map, Crowd Density , Queue Length, License Plate, Rare Sound, Intrusion, Region Entrance, Region Exiting
- Ethernet
- RJ45(10/100BASE-T)
- Video Compression Format
- H.265/H.264/ H.265+/H.264+
- Resolution
- 4MP (2688x1520), 3MP (2304x1296), 1080P (1920x1080), 720P(1280x720) Sub Stream
- Video Quality Adjustment
- 256Kbps ~ 8Mbps
- Bitrate Control Method
- CBR/VBR
- IP
- IPv6
- Protocols
- TCP/IP,HTTP,DHCP,DNS,DDNS,RTPRTSP,SMTP,NTP,UPnP,SNMP,HTTPS,FTP
- Security
- IP address filter;complicated password; Authenticated username and password
- ONVIF
- GST
- Web Viewer
- IE10/11, Safari V12.1 above, Firefox V.52 above Google chrome V.57 above, Edge V.79 above
- Sim Card Type
- Micro SIM
- FREQUENCY
- Band 38/39/40/41; LTE-FDD
- GSM
- GSM850/EGSM900/DCS1800/PCS1900
- Wi-Fi
- IEEE802.11b/g/n; 2.4G
- Environment
- -20°C to 60°C (-4°F to 140°F). Humidity 95% or less (non-condensing)
- Power
- ± 2 W) Solar panels/max.Voltage 14.8V Max.8.7W/Full Power Mode
- Material
- Metal
- Output Voltage
- 12.6V
- Ingress Protection
- IP67
- Wind Resistance
- 12 level
