- Imaging Device
- 1/2.7” Progressive CMOS
- Total Pixels
- 2608 (H) ×1960 (V)
- Effective Pixels
- 2608 (H) ×1960 (V)
- Scanning System
- progressive scanning
- Min. Illumination
- Color 0.04lux @ F1.6 (AGC ON) ; B/W 0 lux @ IR ON
- Max. Framerate
- 5MP@20fps 4AHD/4CVI/4TVI
- Focal Length (Zoom Ratio)
- 2.8-12mm
- Max. Aperture Ratio
- F1.8-3.3
- Angular Field Of View
- 106.6°-34.6°/V
- Min. Object Distance
- 1.2m(W/T)
- Lens Type
- Varifocal Lens
- Safety
- CE LVD
- EMC
- CE EMC, FCC
- ROHS
- RoHS2.0
- IR Distance
- 35M
- On Screen Display
- English
- Day & Night
- Ext / Color / B/W
- Backlight Compensation
- Off / User BLC
- Wide Dynamic Range
- D-WDR (Off/On)
- Digital Noise Reduction
- 2D DNR
- Gain Control
- Auto
- White Balance
- ATW
- Electronic Shutter Speed
- Auto
- Reverse
- Mirror
- Remote Control Interface
- ACP (AHD Coax Protocol)
- Video Transmission Distance
- MAX 300M (RG-6)
- Operating Temperature/Humidity
- -30°C ~ 55°C / 90%
- Ingress Protection
- IP66
- Input Voltage / Current
- 12V DC
- Power Consumption
- IR OFF ≤1W, IR ON ≤4W
- Dimension (WXHXD)
- Ø135.56x127.04mm
- Weight
- Appr. 810g
