- Resolution
- 5MP
- THERMAL
- Yes
- Image Sensor
- Vanadium Oxide Uncooled Focal Plane Arrays
- Max. Resolution
- 256×192
- Pixel Interval
- 12μm
- Response Waveband
- 8-14μm
- NETD (Noise Equivalent Temperature Difference)
- ≤40mk@25°C F#1.0, 25Hz
- Lens (Focal Length)
- 3.2mm
- IFOV
- 3.75 mrad
- Field Of View
- 56°x42°
- Min. Focusing Distance
- 0.3m
- DRI Distance Hum
- 148m (486ft), Recogntion
- DRI Distance Vehicle
- 24m(79ft)
- Heat Detection Distance
- 25m(82t)
- Aperture
- F1.1
- Image Sensor
- 1/2.7” Progressive Scan CMOS
- Min. Illumination
- 0.003 Lux @(F1.6,AGC ON), B/W
- Shutter Speed
- 1/5 s to 1/20000 s
- Field Of View
- 81°, Vertical
- WDR
- 120 dB
- Day & Night
- IR cut filter with auto switch (Day/Night/Auto/Schedule)
- Bi-Spectrum Image Fusion
- Fusion view of thermal view and overlaid details of the optical channel
- Supplement Light Type
- IR and Warm Light
- Supplement Light Range
- Up to 30 m (IR) / 15m (Warm light)
- IR Wavelength
- 850mm
- Smart Supplement Light
- Yes
- Warning Light
- 1 Red & 1Blue flashing light
- Alarm Input
- 1-ch inputs
- Alarm Output
- 1-ch outputs
- Alarm Action
- SD recording/Alarm output/smart capture/FTP upload/ email linkage/ audio alarm/Red & Blue flashing light
- Audio Input
- 1-ch inputs / 1 Built-in MIC
- Audio Output
- 1-ch outputs/ 1 Built-in speaker
- Reset
- Yes
- Communication Interface
- 1, RJ45 10M/100M self-adaptive Ethernet interface.
- SD Memory Card
- Built-on micro SD card slot (up to 1TB)
- Web Browser
- IE10/11, Safari V12.1 above, Firefox V.52 above, Google chrome V.57 above, Edge V.79 above
