Image Sensor
|
Vanadium Oxide Uncooled Focal Plane Arrays
|
|
Max. Resolution
|
256×192
|
|
Pixel Interval
|
12μm
|
|
Response Waveband
|
8-14μm
|
|
NETD (Noise Equivalent Temperature Difference)
|
≤40mk@25°C F#1.0, 25Hz
|
|
Lens (Focal Length)
|
3.2mm
|
|
IFOV
|
3.75 mrad
|
|
Field Of View
|
56°x42°
|
|
Min. Focusing Distance
|
0.3m
|
|
VCA Distance Human
|
18.6m (61ft)
|
|
VCA Distance Vehicle
|
49m (161ft)
|
|
Heat Detection Distance
|
20m(66ft)
|
|
Aperture
|
F1.1
|
|
Max. Image Resolution
|
2592*1944
|
|
Image Sensor
|
1/2.7” Progressive Scan CMOS
|
|
Min. Illumination
|
0.003 Lux @(F1.6,AGC ON), B/W
|
|
Shutter Speed
|
1/5 s to 1/100,000 s
|
|
Lens (Focal Length)
|
3.6mm
|
|
Field Of View
|
81°, Vertical
|
|
WDR
|
120 dB
|
|
Day & Night
|
IR cut filter with auto switch (Day/Night/Auto/Schedule)
|
|
Bi-Spectrum Image Fusion
|
Fusion view of thermal view and overlaid details of the optical channel
|
|
Supplement Light Type
|
IR and Warm Light
|
|
Supplement Light Range
|
Up to 30 m (IR) / 15m (Warm light)
|
|
IR Wavelength
|
850mm
|
|
Smart Supplement Light
|
Yes
|
|
Warning Light
|
1 Red & 1Blue flashing light
|
|
Temperature Measurement
|
Gobal, 12 points, 12 areas, and 12 line.
|
|
Temperature Range
|
-20 °C to + 150 °C (-4 °F to + 302°F)
|
|
Temperature Accuracy
|
± 8 °C (± 14.4 °F)
|
|
Fire Detection
|
Yes
|
|
AI Features
|
Intrusion, Region Entrance, Region Exiting, Line Crossing, Pedestrian & Vehicle, Object Detection, Crossing Counting, Crowd Density, Queue Length, Heat MAP, Rare Sound, Face Detection Thermal
|
|
Main Stream
|
50Hz@25fps; 5MP(2592x1944),4MP(2592x1520),3MP(2304x1296), 1080P(1920x1080), 960P(1280*960),720P(1280x720) 60Hz@30fps; 5MP(2592x1944),4MP(2592x1520),3MP(2304x1296), 1080P(1920x1080), 960P(1280*960),720P(1280x720) Thermal
|
|
Sub-Stream
|
50Hz@25fps; 720P(1280x720),VGA(640x480),QVGA(320x240) 60Hz@30fps; 720P(1280x720),VGA(640x480),QVGA(320x240) Thermal
|
|
Mobile Stream
|
50Hz@25fps; VGA(640x480),QVGA(320x240) 60Hz@30fps; VGA(640x480),QVGA9320x240)
|
|
Video Compression
|
H.265/H.265+/H.264/H.264+MJPEG
|
|
Audio Compression
|
G.711u/G.711a
|
|
Protocols
|
TCP/IP,HTTP,DHCP,DNS,DDNS,RTPRTSP,SMTP,NTP,UPnP,SNMP,HTTPS,FTP
|
|
User/Host Level
|
Administrator, User
|
|
Security Measures
|
User authentication (ID and PW), HTTPS encryption, IP address filtering
|
|
Alarm Input
|
1-ch inputs
|
|
Alarm Output
|
1-ch outputs
|
|
Alarm Action
|
SD recording/Alarm output/smart capture/FTP upload/ email linkage/ audio alarm/Red & Blue flashing light
|
|
Audio Input
|
1-ch
|
|
Audio Output
|
1-ch outputs/ 1 Built-in speaker
|
|
Reset
|
Yes
|
|
Communication Interface
|
1, RJ45 10M/100M self-adaptive Ethernet interface.
|
|
SD Memory Card
|
Built-in micro SD card slot (up to 256GB)
|
|
Analog Video Output(BNC)
|
NA
|
|
Web Browser
|
IE10/11, Safari V12.1 above, Firefox V.52 above, Google chrome V.57 above, Edge V.79 above
|
|
Menu Language
|
English, Russian, German, Italian, French, Portuguese, Spanish, Turkish, Japanese
|
|
Power
|
12 VDC ± 20%, PoE (802.3af)
|
|
Power Consumption
|
Max.10.4W
|
|
Working Temperature/Humidity
|
-35 °C to 60 °C (-31 °F to 140 °F) ; Humidity
|
|
Protection Level
|
IP67
|
|
Dimensions
|
∅108mm*314.6mm(∅4.25”*12.39”)
|
|
Weight
|
Approx. 1.25kg(2.76lb)
|
|
Environment
|
RoHS2.0
|
5MP Resolution
