- Image Sensor
- Vanadium Oxide Uncooled Focal Plane Arrays
- Max. Resolution
- 256×192
- Pixel Interval
- 12μm
- Response Waveband
- 8-14μm
- NETD (Noise Equivalent Temperature Difference)
- ≤40mk@25°C F#1.0, 25Hz
- Lens (Focal Length)
- 3.2mm
- IFOV
- 3.75 mrad
- Field Of View
- 56°x42°
- Min. Focusing Distance
- 0.3m
- VCA Distance Human
- 18.6m (61ft)
- VCA Distance Vehicle
- 49m (161ft)
- Heat Detection Distance
- 20m(66ft)
- Aperture
- F1.1
- Max. Image Resolution
- 2592*1944
- Image Sensor
- 1/2.7” Progressive Scan CMOS
- Min. Illumination
- 0.003 Lux @(F1.6,AGC ON), B/W
- Shutter Speed
- 1/5 s to 1/100,000 s
- Lens (Focal Length)
- 3.6mm
- Field Of View
- 81°, Vertical
- WDR
- 120 dB
- Day & Night
- IR cut filter with auto switch (Day/Night/Auto/Schedule)
- Bi-Spectrum Image Fusion
- Fusion view of thermal view and overlaid details of the optical channel
- Supplement Light Type
- IR and Warm Light
- Supplement Light Range
- Up to 30 m (IR) / 15m (Warm light)
- IR Wavelength
- 850mm
- Smart Supplement Light
- Yes
- Warning Light
- 1 Red & 1Blue flashing light
- Temperature Measurement
- Gobal, 12 points, 12 areas, and 12 line.
- Temperature Range
- -20 °C to + 150 °C (-4 °F to + 302°F)
- Temperature Accuracy
- ± 8 °C (± 14.4 °F)
- Fire Detection
- Yes
- AI Features
- Intrusion, Region Entrance, Region Exiting, Line Crossing, Pedestrian & Vehicle, Object Detection, Crossing Counting, Crowd Density, Queue Length, Heat MAP, Rare Sound, Face Detection Thermal
- Main Stream
- 50Hz@25fps; 5MP(2592x1944),4MP(2592x1520),3MP(2304x1296), 1080P(1920x1080), 960P(1280*960),720P(1280x720) 60Hz@30fps; 5MP(2592x1944),4MP(2592x1520),3MP(2304x1296), 1080P(1920x1080), 960P(1280*960),720P(1280x720) Thermal
- Sub-Stream
- 50Hz@25fps; 720P(1280x720),VGA(640x480),QVGA(320x240) 60Hz@30fps; 720P(1280x720),VGA(640x480),QVGA(320x240) Thermal
- Mobile Stream
- 50Hz@25fps; VGA(640x480),QVGA(320x240) 60Hz@30fps; VGA(640x480),QVGA9320x240)
- Video Compression
- H.265/H.265+/H.264/H.264+MJPEG
- Audio Compression
- G.711u/G.711a
- Protocols
- TCP/IP,HTTP,DHCP,DNS,DDNS,RTPRTSP,SMTP,NTP,UPnP,SNMP,HTTPS,FTP
- User/Host Level
- Administrator, User
- Security Measures
- User authentication (ID and PW), HTTPS encryption, IP address filtering
- Alarm Input
- 1-ch inputs
- Alarm Output
- 1-ch outputs
- Alarm Action
- SD recording/Alarm output/smart capture/FTP upload/ email linkage/ audio alarm/Red & Blue flashing light
- Audio Input
- 1-ch
- Audio Output
- 1-ch outputs/ 1 Built-in speaker
- Reset
- Yes
- Communication Interface
- 1, RJ45 10M/100M self-adaptive Ethernet interface.
- SD Memory Card
- Built-in micro SD card slot (up to 256GB)
- Analog Video Output(BNC)
- NA
- Web Browser
- IE10/11, Safari V12.1 above, Firefox V.52 above, Google chrome V.57 above, Edge V.79 above
- Menu Language
- English, Russian, German, Italian, French, Portuguese, Spanish, Turkish, Japanese
- Power
- 12 VDC ± 20%, PoE (802.3af)
- Power Consumption
- Max.10.4W
- Working Temperature/Humidity
- -35 °C to 60 °C (-31 °F to 140 °F) ; Humidity
- Protection Level
- IP67
- Dimensions
- ∅108mm*314.6mm(∅4.25”*12.39”)
- Weight
- Approx. 1.25kg(2.76lb)
- Environment
- RoHS2.0
