Imaging Device
|
1/2.7”
|
|
Effective Pixels
|
5MP 2880 (H) x 1620 (V)
|
|
Scanning System
|
Progressive CMOS
|
|
Min. Illumination
|
Color 0.002lux @ F1.0(AGC ON) ; B/W 0 lux @ IR ON
|
|
Focal Length (Zoom Ratio)
|
2.8-12mm
|
|
Max. Aperture Ratio
|
F No. 1.2
|
|
Angular Field Of View
|
113(W)-35(T)° V
|
|
Min. Object Distance
|
1.5m
|
|
Lens Type
|
Motorized Ø16.7
|
|
IR LED
|
2
|
|
Warmlight
|
2
|
|
Red & Blue Light
|
2 (1 Red & 1 Blue)
|
|
IR Viewable Length
|
Up to 45m
|
|
Warmlight Viewable Length
|
Up to 25m
|
|
Type Of Complementary Light
|
Default warm light, switchable infrared light
|
|
Motion Detection
|
Off/On (8 Levels)
|
|
Wide Dynamic Range
|
WDR
|
|
Digital Noise Reduction
|
3D DNR
|
|
Image Setting
|
Day&Night Mode/Full Color Mode/Schedule
|
|
White Balance
|
Auto/Manual
|
|
Electronic Shutter Speed
|
1/5 ~ 1/20000s
|
|
On-Board Storage
|
Micro SD slot, up to 1TB
|
|
Alarm
|
1 input, 1 output
|
|
Audio
|
Built-in microphone & Speaker; 1 input (RCA), 1 output (RCA)
|
|
Custom Voice
|
Yes
|
|
Hardware Reset
|
Yes
|
|
Smart Features
|
Rare Sound Detection (SD) , Perimeter Intrusion Detection (PID), Face Detection (FD), Stationary Object Detection (SOD), Crowd Density Detection (CD), Human&Vehicle Detection (PD&VD), Line Crossing Detection (LCD), Queue Lenght Detection (QD), Heat Map (HM), Cross Counting (CC), License Plate Detection (LPD)
|
|
Ethernet
|
RJ45(10/100BASE-T)
|
|
Video Compression Format
|
H.265/H.264
|
|
Resolution
|
Mainstream @30fps 5MP(2880x1620), 4MP(2560X1440) 3MP(2304x1296), 1080P(1920x1080), 720P(1280x720) Substream @30fps 720P(1280x720),VGA(640x480),QVGA(320x240) Mobile Stream @30fps VGA (640x480), QVGA (320x240)
|
|
Video Quality Adjustment
|
256Kbps ~ 8Mbps
|
|
Bitrate Control Method
|
CBR/VBR
|
|
IP
|
IPv6
|
|
Protocol
|
TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP, SMTP,NTP,UPnP,SNMP,HTTPS,FTP
|
|
Security
|
IP address filter;complicated password; Authenticated username and password
|
|
Application Programming Interface
|
ONVIF( Profile S/G/T)
|
|
Web Viewer
|
IE10/11, Safari V12.1 above, Firefox V.52 above Google chrome V.57 above, Edge V.79 above
|
|
Operating Conditions
|
-40~+55°C/less than ≤ 95% RH
|
|
Ingress Protection
|
IP67
|
|
Input Voltage / Current
|
D12V/POE(IEEE802.3af)
|
|
Power Consumption
|
max 5.7W; POE (48V)
|
|
Color/material
|
White/Metal
|
|
Dimension (WXHXD)
|
Ø135x126.5mm
|
|
Weight
|
Appr. 846g
|
5MP Resolution
