5MP RESOLUTION
PRODUCT SPECIFICATIONS
| Imaging Device | 1/2.8” Progressive CMOS |
| Total Pixels | 2704 (H) × 2104 (V) |
| Effective Pixels | 2616 (H) × 1964 (V) |
| Scanning System | progressive scanning |
| Min. Illumination | Color 0.02lux @ F1.6(AGC ON) ; B/W 0 lux @ IR ON |
| Video Output | BNC |
| Resolution | 5MP 2592(H) × 1944(V) |
| Max. Framerate | 5MP@20fps 4AHD/4CVI/4TVI |
| Focal Length (Zoom Ratio) | 2.7-13.5mm |
| Max. Aperture Ratio | F1.8-3.3 |
| Angular Field Of View | 110.6-32.6° / V |
| Min. Object Distance | 0.8m~INF(W),1m~INF(T) |
| Lens Type | Varifocal Lens |
| Safety | CE LVD |
| EMC | CE EMC, FCC |
| ROHS | RoHS2.0 |
| Viewable Length | Up to 35m |
| On Screen Display | English |
| Day & Night | Ext / Color / B/W |
| Backlight Compensation | Off / User BLC |
| Wide Dynamic Range | WDR (Off/On) 120db |
| Digital Noise Reduction | 3D DNR |
| Gain Control | Auto |
| White Balance | ATW |
| Electronic Shutter Speed | Auto |
| Reverse | Mirror |
| Remote Control Interface | ACP (AHD Coax Protocol) |
| Video Transmission Distance | MAX 300M (RG-6) |
| Operating Temperature/Humidity | -30°C ~ 55°C / 90% |
| Ingress Protection | IP66 |
| Input Voltage / Current | 12V DC |
| Power Consumption | IR OFF ≤2W, IR ON ≤6.5W |
| Color/material | metal |
| Dimension (WXHXD) | Ø135.56x127.04mm |
| Weight | appr. 850g |
